Green Micro ATX motherboard with LGA 1200 socket, two DDR4 slots, silver heatsink and rear I/O panel

GIGABYTE

GIGABYTE H410M H V3 LGA 1200 Intel H510 DDR4 Micro ATX motherboard

SKU CH-8NSN-H5N1Y

Micro ATX board with LGA 1200 socket, Intel H510 chipset, two DDR4 slots for up to 64 GB, one M.2 slot, four SATA ports, HDMI 1.4 and 7.1-channel audio

  • CPU Socket TypeLGA 1200
  • CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
  • ChipsetIntel H510
  • Number of Memory Slots2x288pin (DDR4) + 2x240pin
  • Maximum Memory Supported64GB
  • Form FactorMicro ATX
  • LGA 1200 socket supports 10th and 11th Gen Intel Core i9, i7, i5 and i3 processors
  • Intel H510 chipset provides a stable platform for everyday computing tasks
  • Micro ATX form factor fits compact cases while keeping four SATA ports
  • Dual-channel DDR4 memory with two slots allows up to 64 GB capacity
  • HDMI 1.4 output delivers 7.1-channel audio for integrated graphics builds

Micro ATX board for LGA 1200 CPUs

This Micro ATX motherboard uses the Intel H510 chipset and an LGA 1200 socket. It accepts 10th and 11th generation Core i9, i7, i5 and i3 processors. The board fits smaller cases while keeping four SATA ports and one M.2 slot.

Straightforward install with basic checks

Mount the board using standard Micro ATX standoffs and connect the 24-pin ATX power header. The CPU fan header and single chassis fan header are clearly labelled. Remember the memory layout uses two 288-pin DDR4 slots and two 240-pin slots; populate the DDR4 slots first for dual-channel operation.

Dual-channel DDR4 up to 64 GB

Two DDR4 DIMM slots support a maximum of 64 GB in dual-channel mode. Both ECC and non-ECC modules are accepted. This capacity ceiling is the key figure when planning a build around this board.

Highlights

  • LGA 1200 socket supports 10th and 11th Gen Intel Core i9, i7, i5 and i3 processors
  • Intel H510 chipset provides a stable platform for everyday computing tasks
  • Micro ATX form factor fits compact cases while keeping four SATA ports
  • Dual-channel DDR4 memory with two slots allows up to 64 GB capacity
  • HDMI 1.4 output delivers 7.1-channel audio for integrated graphics builds

Specifications

CPU Socket TypeLGA 1200
CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
ChipsetIntel H510
Number of Memory Slots2x288pin (DDR4) + 2x240pin
Maximum Memory Supported64GB
Form FactorMicro ATX

Questions about this item

How can I verify the H410M H V3 is working after assembly?

Power on the board and confirm the CPU fan spins, the HDMI 1.4 port outputs video, and the BIOS reports memory in dual-channel mode.

What comes in the box and what must I purchase separately?

The motherboard includes one M.2 slot, four SATA ports, two USB 3.2 Gen 1 headers, two USB 2.0 headers, and a TPM header; you must supply an LGA 1200 processor, DDR4 DIMMs, storage drives, and a chassis with a 24-pin ATX power supply.

Which memory capacity should I choose for the two DDR4 slots?

The H510 chipset supports up to 64 GB total; populate both DIMM slots with matching DDR4 modules to reach the desired capacity within that limit.
