Green rectangular Micro ATX motherboard with black slots and silver heatsinks

GIGABYTE

GIGABYTE H410M S2 V2 H470 LGA 1200 DDR4 Micro ATX Intel motherboard

SKU CH-CXQP-F4YJB

Micro ATX Intel board with H470 chipset, LGA 1200 socket, dual-channel DDR4 up to 64 GB and integrated graphics output

  • CPU TypeIntel Core 10th Gen (LGA 1200)
  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Intel H470 Express chipset provides platform features
  • Dual-channel DDR4 memory up to 64 GB across two DIMM slots
  • Integrated Intel HD Graphics output through D-Sub at 1920x1200 60 Hz
  • Realtek High Definition Audio with 7.1-channel surround support

H410M S2 V2 Intel H470 LGA 1200 DDR4 Micro ATX

This micro ATX board uses the Intel H470 Express Chipset with an LGA 1200 socket for 10th Generation Intel Core i9, i7, i5, i3, Pentium and Celeron processors. It provides two DDR4 DIMM slots supporting up to 64 GB of system memory in dual channel mode. Integrated Intel HD Graphics drive a single D-Sub output at up to 1920x1200@60 Hz with 512 MB shared memory. Builders needing more than two memory slots or additional display outputs should consider a larger form factor.

Thermals noise and power draw

The H470 chipset and voltage regulation run at typical desktop power levels with passive heatsinks, so system noise depends on the chosen CPU cooler and case airflow rather than the board itself. Memory operates at standard DDR4 voltages with XMP profile support for automatic timing configuration. No active cooling components are integrated on the motherboard.

Bundled accessories and software impact

Realtek High Definition Audio CODEC enables 2, 4, 5.1 and 7.1 channel output through onboard ports, with 7.1 channel configuration available via audio software. Driver and utility downloads from the manufacturer provide chipset, audio and BIOS update support. No additional expansion cards, cables or proprietary software suites are included in the package.

Highlights

  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Intel H470 Express chipset provides platform features
  • Dual-channel DDR4 memory up to 64 GB across two DIMM slots
  • Integrated Intel HD Graphics output through D-Sub at 1920x1200 60 Hz
  • Realtek High Definition Audio with 7.1-channel surround support

Specifications

CPU TypeIntel Core 10th Gen (LGA 1200)

Questions about this item

How do I install the processor into the LGA 1200 socket without bending pins?

Lift the retention lever, align the notches on the CPU with the socket keys, place the chip gently without pressure, lower the frame and lock the lever back down; the common mistake is forcing the CPU before the notches are perfectly seated.

What component will need replacement first during long-term ownership?

The onboard CMOS battery that maintains BIOS settings and system time will eventually deplete and require a replacement cell to keep the board starting reliably.

Which limit appears first when the VRM runs under sustained heavy load?

The 4+2 phase power delivery feeding the LGA 1200 socket reaches its thermal ceiling before the chipset does, so VRM temperature becomes the bottleneck during prolonged all-core workloads.
