Green micro-ATX board with black sockets and silver heatsink

GIGABYTE

GIGABYTE H410M S2H V2 Intel motherboard

SKU CH-1CAH-PBJ2K

Micro-ATX board for 10th Gen Intel Core CPUs with dual-channel DDR4 to 64 GB, PCIe 3.0 x16, M.2 PCIe 3.0 x4 or SATA, four SATA 6Gb/s ports, Intel GbE LAN and 7.1-channel audio

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core processors Supports Intel Penti
  • ChipsetIntel H470
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots2x288pin (DDR4)
  • Memory StandardDDR4 2933 / 2666 / 2400 / 2133 (Intel Core i9 / i7 processor
  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB across two 288-pin slots
  • Ultra-fast M.2 slot for PCIe 3.0 x4 and SATA SSDs in 2242/2260/2280 sizes
  • Intel Gigabit LAN with cFosSpeed software for smoother network traffic
  • HDMI, DVI-D and D-Sub outputs enable multi-display setups

LGA 1200 Micro-ATX Platform

The GIGABYTE H410M S2H V2 is a micro-ATX board built for Intel LGA 1200 processors. It supports 10th Gen Core, Pentium and Celeron CPUs on the H470 chipset. Integrated graphics output is available when the installed processor provides it. The form factor suits compact chassis builds.

64 GB Dual-Channel DDR4 and M.2 Headroom

Two 288-pin slots accept DDR4 up to 2933 MT/s with Core i9 or i7, and 2666 MT/s with i5, i3, Pentium or Celeron. Maximum capacity is 64 GB in dual-channel mode. One M.2 socket 3 M key takes 2242, 2260 or 2280 drives using SATA or PCIe 3.0 x4/x2. Four SATA 6Gb/s ports add further storage lanes.

PCIe 3.0 Expansion and Core I/O

A single PCIe 3.0 x16 slot handles a discrete graphics card. Two PCIe 3.0 x1 slots accept add-in cards such as sound or capture devices. Rear I/O includes HDMI, DVI-D and D-Sub for multi-display setups, Intel GbE LAN at 1 Gbps and USB 3.2 Gen 1 ports. Realtek 7.1-channel audio and Smart Fan 5 headers complete the platform.

Highlights

  • Supports 10th Gen Intel Core processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 64 GB across two 288-pin slots
  • Ultra-fast M.2 slot for PCIe 3.0 x4 and SATA SSDs in 2242/2260/2280 sizes
  • Intel Gigabit LAN with cFosSpeed software for smoother network traffic
  • HDMI, DVI-D and D-Sub outputs enable multi-display setups

Specifications

BrandGIGABYTE
ModelH410M S2H V2
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core processors
Supports Intel Pentium and Celeron processors
ChipsetIntel H470
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2933 / 2666 / 2400 / 2133 (Intel Core i9 / i7 processors)
DDR4 2666 / 2400 / 2133 (Intel Core i5 / i3 / Pentium / Celeron processors)
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express x12 x PCI Express 3.0 x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)
Intel Optane ReadyYes
SATA RAID0/1/5/10
Audio ChipsetRealtek Audio CODEC
Audio Channels7.1 Channels
LAN ChipsetIntel GbE LAN chip
Max LAN Speed1Gbps
Back I/O Ports1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x CPU fan header
1 x system fan header
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x speaker header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper
Windows 11Supported
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)8.9" x 7.3"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
FeaturesI/O Controller:
iTE I/O Controller Chip
H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS:
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features:
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
Ambient LE

Questions about this item

Will my existing DDR4 2666 MHz modules work in the two 288-pin slots on this H410M S2H V2?

Yes, the board supports DDR4 at 2666 MHz with Core i5, i3, Pentium or Celeron CPUs and runs up to 2933 MHz with i9 or i7 processors in dual-channel mode.

How can I confirm the M.2 SSD is running at PCIe 3.0 x4 speed after installation?

Check the BIOS M.2 information screen or use a Windows tool such as CrystalDiskInfo to verify the link shows PCIe 3.0 x4 rather than x2 or SATA mode.

Does the box include the I/O shield and SATA cables, or must I buy them separately?

The retail package contains the motherboard, I/O shield, two SATA 6Gb/s cables, driver disc and quick-install guide; no extra cables are required for basic assembly.
