Green Micro ATX board with silver CPU socket, two black RAM slots, one long PCIe x16 slot, two short PCIe x1 slots, four SATA ports

GIGABYTE

GIGABYTE H510M D2VX SI LGA 1200 Intel motherboard

SKU CH-J383-YYAQ3

Micro ATX board for LGA 1200 CPUs with Intel H510 chipset, dual DDR4 slots up to 64 GB, one PCI-E 4.0 x16 slot, two PCI-E 3.0 x1 slots, four SATA III ports, one M.2 socket.

  • CPU Socket TypeLGA 1200
  • CPU TypeLGA1200 slot, supports: 11th generation Intel ® Core ™ i9 pr
  • ChipsetIntel H510
  • Maximum Memory Supported64GB
  • PCI Slots1 PCI-E x16 slot, supporting x16 operating specifications (P
  • SATA RAID1XM.2 interface, 4xSATA III interface
  • Supports 10th and 11th generation Intel Core i9, i7 and i5 processors via LGA 1200 socket
  • Up to 64GB DDR4 memory across two DIMM slots for high capacity
  • PCIe 4.0 x16 slot with 11th generation CPUs for faster graphics bandwidth
  • Micro ATX 24.4x21cm form factor fits compact builds
  • Realtek GbE LAN and 7.1 channel audio for networking and sound

LGA 1200 micro-ATX board for 10th

This GIGABYTE H510M D2VX SI motherboard fits the LGA 1200 socket and accepts 10th and 11th generation Intel Core i9, i7 and i5 processors. The micro-ATX form factor measures 24.4 by 21 cm and provides two DDR4 DIMM slots. It is aimed at builders who need a compact Intel platform without enthusiast features.

PCI Express 4.0 on the x16 slot only

The board carries one PCI Express x16 slot that runs at PCI Express 4.0 speeds when an 11th generation processor is installed; with a 10th generation CPU it operates at the lower generation. Two additional PCI Express x1 slots run at PCI Express 3.0. Four SATA III ports and one M.2 interface handle storage, while the Realtek GbE LAN controller is limited to 1 Gbit and 100 Mbit rates.

Maximum memory capacity is 64 GB across two slots

The chipset supports up to 64 GB of DDR4 memory, which must be populated across the two available DIMM slots. This ceiling decides whether the board suits a given workload; systems needing more memory will require a different chipset. Onboard USB provides four USB 3.2 Gen 1 ports and six USB 2.0 ports, and the Realtek audio codec supports up to 7.1 channel output.

Highlights

  • Supports 10th and 11th generation Intel Core i9, i7 and i5 processors via LGA 1200 socket
  • Up to 64GB DDR4 memory across two DIMM slots for high capacity
  • PCIe 4.0 x16 slot with 11th generation CPUs for faster graphics bandwidth
  • Micro ATX 24.4x21cm form factor fits compact builds
  • Realtek GbE LAN and 7.1 channel audio for networking and sound

Specifications

BrandGIGABYTE
SeriesGIGABYTE H510M D2VX SI
ModelGIGABYTE H510M D2VX SI
CPU Socket TypeLGA 1200
CPU TypeLGA1200 slot, supports:
11th generation Intel ® Core ™ i9 processor/Intel ® Core ™ i7 processor/Intel ® Core ™ i5 processor
10th Gen Intel ® Core ™ i9 Processor/Intel ® Core ™ i7 Processor/Intel ® Core ™ i5 Processor/Intel ® Core ™ i3 Processor/Intel ® Pentium ® Processor/Intel ® Celeron ® Processor *
** 4 MB Intel ® Smart Cache, i.e. Intel ® Celeron ® G5xx5 series processors
3. L3 cache depends on CPU
ChipsetIntel H510
Maximum Memory Supported64GB
PCI Slots1 PCI-E x16 slot, supporting x16 operating specifications
(PCIEX16 slot supports PCI-E 4.0) *
Only the 11th generation processors support this feature.
2 PCI-E x1 slots
(PCIEX1 slot supports PCI-E 3.0)
SATA RAID1XM.2 interface, 4xSATA III interface
Audio Chipset1. Integrated Realtek ® audio chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 - Channel
LAN ChipsetIntegrated Realtek ® GbE network chips (1 Gbit/100 Mbit)
Onboard USBBased on chipset:
1.4 USB 3.2 Gen 1 ports (2 in the rear window IO, 2 need to be connected from the USB socket in the main board via the cable)
2.6 USB 2.0/1 (4 in the rear window IO, 2 need to be connected from the main board USB socket via cable)

Questions about this item

Will an 11th generation Intel Core i5 fit this LGA 1200 socket?

Yes, the board supports 11th generation Intel Core i9, i7 and i5 processors in the LGA 1200 socket.

How many DDR4 memory modules can I install and what is the total limit?

Two DDR4 DIMM slots are provided with a maximum capacity of 64 GB.

Does the PCIe x16 slot run at 4.0 speeds with a 10th generation CPU?

PCIe 4.0 on the x16 slot is only active when an 11th generation processor is installed.
