Green Micro ATX motherboard with silver LGA 1200 socket, black slots, blue I/O shield

GIGABYTE

GIGABYTE H510M H Intel H510 LGA 1200 Micro ATX Motherboard

SKU CH-F487-4JSFR

Supports 10th and 11th Gen Intel Core i9, i7, i5 and i3 processors in a Micro ATX form factor with up to 64GB DDR4 memory

  • CPU Socket TypeLGA 1200
  • CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
  • ChipsetIntel H510 Express
  • Form FactorMicro ATX
  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • 64 GB dual-channel DDR4 memory capacity for multitasking headroom
  • Micro ATX form factor fits compact chassis builds
  • Smart Fan 6 with 7-point curves and 24 W headers enables precise cooling control
  • HDMI plus USB 3.2 Gen 1 and USB 2.0 ports cover essential display and peripheral needs

H510 Micro ATX Board for 10th

The GIGABYTE H510M H uses the Intel H510 Express chipset on a Micro ATX form factor. It fits LGA 1200 processors from the 10th and 11th generation Core i9, i7, i5 and i3 families. The board provides dual-channel DDR4 memory support up to 64 GB. Essential rear I/O includes one HDMI port, one Gigabit Ethernet jack, two USB 3.2 Gen 1 Type-A ports and four USB 2.0 ports.

Smart Fan 6 Cooling Under Continuous Load

Smart Fan 6 manages thermals during extended sessions with multiple hybrid fan headers that accept PWM or DC fans and water-cooling pumps. Each header delivers up to 24 W with over-current protection. The BIOS interface offers seven temperature and speed control points plus Slope and Stair curve modes for linear or stepped fan behaviour. Manual input and EZ Tuning points allow precise, quiet operation when the system runs hot for long periods.

64 GB Dual-Channel DDR4 Capacity Limit

The memory controller supports a maximum of 64 GB across two dual-channel DDR4 slots. This ceiling determines whether the board suits a given workload; builds that require more memory must choose a different platform. No other specification in the data overrides this limit.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • 64 GB dual-channel DDR4 memory capacity for multitasking headroom
  • Micro ATX form factor fits compact chassis builds
  • Smart Fan 6 with 7-point curves and 24 W headers enables precise cooling control
  • HDMI plus USB 3.2 Gen 1 and USB 2.0 ports cover essential display and peripheral needs

Specifications

CPU Socket TypeLGA 1200
CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
ChipsetIntel H510 Express
Form FactorMicro ATX

Questions about this item

How loud and hot does the Smart Fan 6 system get when the board runs all day?

Smart Fan 6 uses up to seven temperature points and dual curve modes to keep fan speeds low and steady under sustained load. Each header supplies up to 24 W with over-current protection, so cooling stays controlled and quiet.

What memory and processor must I already have to use this LGA 1200 board?

You need a 10th or 11th Gen Intel Core i9, i7, i5 or i3 CPU and DDR4 modules up to 64 GB in dual-channel configuration.

Will my existing USB 2.0 peripherals and HDMI monitor work with the rear I/O on this H510 board?

Yes, the rear panel provides four USB 2.0 ports, two USB 3.2 Gen 1 Type-A ports and one HDMI output for direct compatibility.
