Green micro-ATX motherboard with silver CPU socket and black PCIe slot

GIGABYTE

GIGABYTE H510M H V2 Intel motherboard

SKU CH-MTMC-WCYEZ

Micro-ATX board for LGA 1200 Intel 10th and 11th Gen CPUs with H510 chipset, two DDR4 slots up to 64 GB, PCIe 4.0 x16, HDMI and 1 Gbps LAN

  • CPU Socket TypeLGA 1200
  • CPU Type10TH 11TH
  • Supported CPU TechnologiesINTEL
  • ChipsetH510
  • Number of Memory Slots2xDDR4
  • Memory StandardDDR4 2133
  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Intel H510 chipset delivers essential platform features for everyday computing
  • Two DDR4 slots accept up to 64 GB in dual-channel mode
  • PCI Express 4.0 x16 slot ready for modern graphics cards
  • Micro-ATX form factor fits compact chassis builds

GIGABYTE H510M H V2 Micro-ATX Motherboard

The GIGABYTE H510M H V2 is a Micro-ATX motherboard built around the Intel H510 chipset for LGA 1200 processors. It supports 10th and 11th Generation Intel Core i9, i7, i5, i3, Pentium and Celeron CPUs. The board provides two DDR4 DIMM slots with a maximum capacity of 64 GB and dual-channel architecture. A single PCI Express x16 slot and one HDMI output handle graphics and display connectivity.

Suits 10th or 11th Gen Intel builds

This board suits builders assembling a compact system with a 10th or 11th Generation Intel processor and up to two memory modules. Integrated graphics users can connect a display via the HDMI port. Builders needing four DIMM slots, multiple PCI Express x16 slots or a chipset other than H510 should look at larger form-factor alternatives.

Two DDR4 slots define the memory ceiling

The two DDR4 slots set a hard limit of 64 GB total system memory using 32 GB modules. Supported speeds depend on the installed CPU generation: 11th Gen Core i9, i7 and i5 reach up to 3200 MHz; 10th Gen Core i9 and i7 reach up to 2933 MHz; 10th Gen Core i5, i3, Pentium and Celeron reach up to 2666 MHz. All configurations fall back to the base 2133 MHz standard.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Intel H510 chipset delivers essential platform features for everyday computing
  • Two DDR4 slots accept up to 64 GB in dual-channel mode
  • PCI Express 4.0 x16 slot ready for modern graphics cards
  • Micro-ATX form factor fits compact chassis builds

Specifications

BrandGIGABYTE
ModelH510M H V2
CPU Socket TypeLGA 1200
CPU Type10TH 11TH
Supported CPU TechnologiesINTEL
ChipsetH510
Number of Memory Slots2xDDR4
Memory StandardDDR4 2133
Maximum Memory Supported64GB
Channel Supported2
PCI Express x161 x PCI Express x16
Audio ChipsetHigh Definition Audio
Max LAN Speed1Gbps
HDMI1 x HDMI
Form FactorMicro ATX

Questions about this item

Should I pick a 32 GB kit or two 32 GB modules to reach the 64 GB limit?

The board has two DDR4 slots and supports up to 64 GB total, so two 32 GB modules are required to reach the maximum capacity.

What memory speed will I actually see with an 11th Gen Core i5 installed?

With an 11th Gen Core i5 the board supports DDR4 up to 3200 MHz, but the default JEDEC speed is 2133 MHz unless XMP is enabled in BIOS.

Does the PCI Express 4.0 x16 slot run at full 4.0 speed with a 10th Gen processor?

PCI Express 4.0 is only available when an 11th Gen CPU is installed; with a 10th Gen CPU the slot operates at PCI Express 3.0 speeds.
