Green micro-ATX board with silver LGA 1200 socket and PCIe 4.0 x16 slot

GIGABYTE

GIGABYTE H510M H V2 PCIE4.0X16 3200 Intel motherboard

SKU CH-6R83-WVDFH

Micro-ATX board for LGA 1200 CPUs with PCIe 4.0 x16 and DDR4 up to 3200 MHz

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Intel H470 chipset provides platform features for mainstream builds
  • Dual-channel DDR4 memory up to 3200 MHz with XMP support
  • Two DIMM slots accept up to 64 GB total system memory
  • PCIe 4.0 x16 slot enables high-bandwidth graphics cards

Socket and chipset

The GIGABYTE H510M H V2 is a micro-ATX motherboard built around the Intel H470 Express chipset and an LGA 1200 socket. It supports 10th and 11th Generation Intel Core i9, i7, i5, i3, Pentium and Celeron processors. The board targets budget-conscious builders who need a compact foundation for everyday computing and light gaming.

Installation notes

The board uses a standard micro-ATX layout with two DDR4 DIMM slots and a single PCIe 4.0 x16 slot for a graphics card. Memory installation is straightforward, but the two-slot limit means you must choose capacity carefully at build time. CPU cooler clearance depends on the case and the specific cooler model; check both before purchasing.

Memory capacity and limits

Two DIMM sockets accept up to 64 GB of DDR4 in a dual-channel configuration, with a maximum of 32 GB per module. Supported speeds vary by processor generation: 11th Generation Core i9, i7 and i5 CPUs enable up to 3200 MHz, while 10th Generation Core i9 and i7 top out at 2933 MHz and other 10th Generation chips at 2666 MHz. XMP profiles are supported for automatic overclocking within these limits.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Intel H470 chipset provides platform features for mainstream builds
  • Dual-channel DDR4 memory up to 3200 MHz with XMP support
  • Two DIMM slots accept up to 64 GB total system memory
  • PCIe 4.0 x16 slot enables high-bandwidth graphics cards

Specifications

No published specifications for this item yet.

Questions about this item

How do I verify the board is running DDR4 3200 MHz after installing an 11th Gen Core i5?

Enter the BIOS and confirm the memory frequency reads 3200 MHz; the board supports DDR4 3200/3000/2933/2666/2400/2133 MHz with 11th Gen Core i9/i7/i5 CPUs.

What comes in the box and what must I buy separately?

The motherboard ships alone; you must purchase a compatible LGA1200 processor, DDR4 DIMMs (up to 64 GB total, 32 GB per slot), and a CPU cooler.

Which memory speed should I choose for a 10th Gen Core i3 build?

With 10th Gen Core i3/Pentium/Celeron CPUs the board supports DDR4 2666/2400/2133 MHz, so select a kit rated for 2666 MHz or lower.
