Green Micro ATX motherboard with black PCB, silver CPU socket cover, two vertical DDR4 slots, single M.2 slot, PCIe x16 slot

GIGABYTE

GIGABYTE H610M S2H DDR4 Intel motherboard

SKU CH-BA1J-SSG97

Micro-ATX board for 12th and 13th Gen Intel CPUs with dual-channel DDR4, one PCIe 4.0 x16 slot, a single M.2 NVMe 3.0 x4 drive, four SATA ports and gigabit LAN

  • CPU Socket TypeLGA 1700 * Dedicated LGA1700 mounting bracket is required.
  • CPU TypeSupports 13th / 12th Gen Intel Core, Pentium Gold, Celeron P
  • ChipsetIntel H610
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots2x288pin (DDR4)
  • Memory StandardDDR4 3200
  • Supports 12th and 13th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR4 3200 memory up to 64 GB across two 288-pin slots
  • 6+1+1 hybrid digital VRM design delivers stable power for daily workloads
  • PCIe 4.0 x16 slot plus single M.2 NVMe PCIe 3.0 x4 for fast storage
  • Realtek 1 GbE LAN and USB 3.2 Gen1 ports provide essential connectivity

GIGABYTE H610M S2H DDR4 for Intel LGA 1700 builds

This Micro ATX motherboard uses the Intel H610 chipset and an LGA 1700 socket. It supports 12th and 13th Gen Intel Core, Pentium Gold and Celeron processors. Two 288‑pin DDR4 slots run dual‑channel memory up to 3200 MT/s with a 64 GB maximum. Onboard video works only when the installed CPU includes integrated graphics.

Installation notes and common issues

A dedicated LGA 1700 mounting bracket is required for the cooler. The board provides one PCIe 4.0 x16 slot, four SATA 6Gb/s ports and a single M.2 connector wired for PCIe 3.0 x4 NVMe. USB 3.2 Gen1 headers and Realtek GbE LAN are included. Builders sometimes forget the bracket or populate the wrong M.2 key.

Compatibility checks before ordering

Verify that your case accepts Micro ATX dimensions and that the power supply carries the necessary CPU and motherboard connectors. Confirm the chosen CPU has integrated graphics if you need video output without a discrete card. Ensure any M.2 drive you plan to use is an NVMe model compatible with PCIe 3.0 x4 signalling.

Highlights

  • Supports 12th and 13th Gen Intel Core processors on LGA 1700 socket
  • Dual-channel DDR4 3200 memory up to 64 GB across two 288-pin slots
  • 6+1+1 hybrid digital VRM design delivers stable power for daily workloads
  • PCIe 4.0 x16 slot plus single M.2 NVMe PCIe 3.0 x4 for fast storage
  • Realtek 1 GbE LAN and USB 3.2 Gen1 ports provide essential connectivity

Specifications

BrandGIGABYTE
ModelH610M S2H DDR4
CPU Socket TypeLGA 1700
* Dedicated LGA1700 mounting bracket is required.
CPU TypeSupports 13th / 12th Gen Intel Core, Pentium Gold, Celeron Processors
ChipsetIntel H610
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 3200
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x NVMe PCIe 3.0 x4 M.2
Max LAN Speed1Gbps
Windows 11Supported
Form FactorMicro ATX

Questions about this item

How do I confirm the 6+1+1 Hybrid Digital VRM is delivering stable power after I install a 13th Gen Intel Core processor?

Enter the BIOS hardware monitor and verify the CPU Vcore reading stays within Intel specifications under load; the board has no debug LEDs so the BIOS voltage readout is the primary check.

Which cables or brackets are not included with the H610M S2H DDR4 that I must source separately?

A dedicated LGA 1700 mounting bracket for the CPU cooler is required and not supplied; SATA data cables for the four 6 Gb/s ports and an M.2 mounting screw for the single NVMe PCIe 3.0 x4 slot are also typically sold separately.

Should I choose a 32 GB kit or two 32 GB modules to reach the 64 GB maximum on this dual-channel DDR4 3200 board?

The board has two 288-pin slots and supports 64 GB total, so a 2 x 32 GB DDR4 3200 kit is the only way to reach the limit; a single 32 GB module leaves the second slot empty and caps capacity at 32 GB.
