ATX motherboard in black finish with four DDR3 slots and silver heatsinks

GIGABYTE

GIGABYTE H97-D3H rev.1.0 LGA 1150 Intel H97 DDR3 32GB ATX motherboard

SKU CH-86M5-QXDAR

LGA 1150 ATX board with Intel H97 chipset, four DDR3 slots for up to 32 GB, PCIe 3.0 x16, six SATA III plus SATA Express and M.2, Intel gigabit LAN and Realtek ALC1150 7.1 audio

  • CPU Socket TypeLGA 1150
  • CPU Type1. Support LGA1150 Slot Processor: Intel Core ™ i7 Processor
  • ChipsetIntel H97
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID1XM.2 interface, 1xSATA Express interface, 6xSATA III interf
  • Supports 32GB DDR3 for multitasking headroom
  • LGA 1150 socket fits Core i7, i5, i3, Pentium and Celeron CPUs
  • PCI Express 3.0 x16 slot enables full graphics-card bandwidth
  • Intel GbE LAN delivers 1000 Mbit wired networking
  • Realtek ALC1150 audio provides 7.1-channel high-definition sound

Socket LGA 1150 ATX board

The GIGABYTE H97-D3H rev.1.0 is an ATX motherboard built around the Intel H97 chipset for LGA 1150 processors. It accepts Core i7, i5, i3, Pentium and Celeron CPUs and provides four DDR3 DIMM slots for up to 32GB of system memory.

Sustained-load behaviour

The board uses solid capacitors and a reinforced PCI Express x16 slot rated for PCI Express 3.0 x16 operation, helping the graphics card maintain full bandwidth during extended sessions. An onboard Intel GbE controller handles 10/100/1000 Mbit networking without adding extra latency under continuous traffic.

Storage connectivity mix

One M.2 interface, one SATA Express interface and six SATA III ports give a wide choice of drive configurations for the operating system, applications and bulk data. The Realtek ALC1150 audio codec supports 7.1-channel output and S/PDIF for home-theatre or headset use.

Highlights

  • Supports 32GB DDR3 for multitasking headroom
  • LGA 1150 socket fits Core i7, i5, i3, Pentium and Celeron CPUs
  • PCI Express 3.0 x16 slot enables full graphics-card bandwidth
  • Intel GbE LAN delivers 1000 Mbit wired networking
  • Realtek ALC1150 audio provides 7.1-channel high-definition sound

Specifications

BrandGIGABYTE
SeriesGIGABYTE H97-D3H(rev.1.0)
ModelGIGABYTE H97-D3H(rev.1.0)
CPU Socket TypeLGA 1150
CPU Type1. Support LGA1150 Slot Processor: Intel Core ™ i7 Processor/Intel Core ™ i5 Processor/Intel Core ™ i3 Processor/Intel Pentium Processor/Intel Celeron Processor
2. L3 cache depends on CPU
ChipsetIntel H97
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
(PCIEX16 slot supports PCI Express 3.0)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
Due to the fact that all PCI Express x1 slots share bandwidth with PCIEX4 slots, all PCI Express x1 slots will become unusable when PCIEX4 slots are equipped with expansion cards of PCIe x4 specification or higher.
When installing an expansion card with a bandwidth of x8
SATA RAID1XM.2 interface, 1xSATA Express interface, 6xSATA III interface
Audio Chipset1. Built-in Realtek ALC1150 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
4. Support S/PDIF output
LAN ChipsetBuilt-in Intel GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1.6 USB 3.0/2 ports (4 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
2.8 USB 2.0/1 ports (2 on the rear panel, 6 to be connected from the USB socket in the main board via cable)

Questions about this item

How much power does the H97-D3H draw when the system runs all day?

The board uses the Intel H97 chipset and supports LGA 1150 processors up to 32 GB of DDR3; actual all-day power draw depends on the specific CPU and graphics card you install.

Which components must I already own for this motherboard to work?

You need an LGA 1150 processor (Core i7, i5, i3, Pentium or Celeron), up to four DDR3 DIMMs totalling no more than 32 GB, a graphics card for the PCI Express 3.0 x16 slot, storage for the six SATA III ports plus one SATA Express and one M.2 interface, and an ATX power supply with 24-pin and 4/8-pin CPU connectors.

Will my older SATA drives and DDR3 memory work with this board?

Yes — the H97-D3H provides six SATA III ports, one SATA Express port and one M.2 interface for existing SATA drives, and four DDR3 DIMM slots supporting up to 32 GB of memory.
