Green E-ATX server motherboard with silver LGA 4677 socket, sixteen black DDR5 DIMM slots and multiple PCIe x16 slots

GIGABYTE

GIGABYTE MS33-CP0 server motherboard LGA 4677 16 DDR5 5600 E-ATX

SKU CH-AMMD-3SFZT MPN MS33-CP0

Single-processor server motherboard with LGA 4677 socket, 16 DDR5 5600 slots and PCIe 5.0 x16 expansion

  • CPU Socket TypeLGA 4677
  • CPU Type4th Gen Intel Xeon Scalable / 5th Gen Intel Xeon Scalable /
  • Number of Processor Support1
  • CPU FeaturesSingle processor, TDP up to 350W
  • North BridgeIntel C741
  • Memory Slots16 x DDR5 288-pin
  • Single-socket design supports up to 350W TDP CPUs
  • Eight-channel DDR5 architecture with 16 slots for 4TB capacity
  • Three PCIe 5.0 x16 slots for high-bandwidth accelerators
  • Two MCIO 8i connectors enable four Gen5 NVMe drives
  • Dual 1GbE LAN plus Aspeed AST2600 remote management

Single-processor Xeon platform

The GIGABYTE MS33-CP0 is an E-ATX server motherboard built for one 4th or 5th Gen Intel Xeon Scalable processor or an Intel Xeon CPU Max series chip in the LGA 4677 socket. It targets compute nodes that need eight-channel DDR5 memory and PCIe 5.0 expansion in a single-socket design.

PCIe 5.0 lane allocation limits

Three full-length slots deliver Gen5 x16, x16 and x8 electrical connections, while a fourth slot shares its Gen5 x8 lanes with the first slot. Two MCIO 8i connectors provide four Gen5 NVMe links, and the single M.2 slot is restricted to PCIe Gen3 x4 from the PCH.

Eight-channel DDR5 capacity ceiling

Sixteen 288-pin RDIMM slots support DDR5 5600 for a maximum of 4 TB across eight channels. Builders needing more than one processor, more than sixteen DIMM sites or Gen5 speeds on the M.2 interface must choose a different platform.

Highlights

  • Single-socket design supports up to 350W TDP CPUs
  • Eight-channel DDR5 architecture with 16 slots for 4TB capacity
  • Three PCIe 5.0 x16 slots for high-bandwidth accelerators
  • Two MCIO 8i connectors enable four Gen5 NVMe drives
  • Dual 1GbE LAN plus Aspeed AST2600 remote management

Specifications

BrandGIGABYTE
ModelMS33-CP0
CPU Socket TypeLGA 4677
CPU Type4th Gen Intel Xeon Scalable / 5th Gen Intel Xeon Scalable / Intel Xeon CPU Max
Number of Processor Support1
CPU FeaturesSingle processor, TDP up to 350W
North BridgeIntel C741
Memory Slots16 x DDR5 288-pin
Memory StandardDDR5 5600
Maximum Memory Supported4TB
Channel SupportedEight Channel
RegisteredYes
PCI Express 5.0 x16Slot_6: PCIe x16 (Gen5 x16) slot
Slot_4: PCIe x16 (Gen5 x16) slot
Slot_2: PCIe x16 (Gen5 x16 or x8) slot, shared with Slot_1
Slot_1: PCIe x16 (Gen5 x8) slot
Other Slots2 x MCIO 8i connectors for 4 x Gen5 NVMe
SATA2 x SATA 6.0Gb/s
SATA RAID0/1/10/5
SAS2 x SlimSAS connectors for 8 x SATA 6Gb/s
M.21 x M.2 slot:
- M-key
- PCIe Gen3 x4, from PCH
- Supports 2280/22110 cards
Onboard Video ChipsetAspeed AST2600
LAN ChipsetIntel I210-AT
LAN Speed10/100/1000Mbps
Max LAN Speed2 x 1Gbps
Back I/O Ports2 x USB 3.2 Gen1
1 x Mini-DP
2 x RJ45
1 x MLAN
1 x ID button with LED
Onboard USB1 x USB 3.2 Gen1 x2 header
Other Connectors1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
2 x CPU fan headers
5 x System fan headers
1 x M.2 slot
2 x MCIO 8i connectors
2 x SlimSAS connectors
2 x SATA connectors
1 x Front panel header
1 x Backplane board header
1 x PMBus header
1 x IPMB header
1 x TPM header
Form FactorExtended ATX
Dimensions (W x L)12" x 13"
Package Contents1 x MS33-CP0
1 x I/O shield
1 x Quick start guide
3 x Carriers
1 x SlimSAS to 4 x SATA 6Gb/s cable (600mm)
Contains Embedded BatteryNo
Shipping weight1.81 kg
Package size406 × 356 × 76 mm

Questions about this item

Which DDR5 speed should I select for the 5600 MT/s memory slots?

Use DDR5-5600 RDIMM modules; the board runs eight-channel DDR5 at up to 5600 MT/s across its 16 slots.

What does the 350 W TDP rating mean for my CPU cooler choice?

The socket supports a single processor with a thermal design power up to 350 W, so choose a cooler rated for at least that heat load.

How many Gen5 NVMe drives can the MCIO connectors run simultaneously?

Two MCIO 8i connectors each provide a PCIe 5.0 x8 link, giving four Gen5 NVMe drives at full x4 bandwidth.
