Green ATX motherboard with silver heatsinks and black slots

GIGABYTE

GIGABYTE W480 VISION W Intel motherboard

SKU CH-PPDW-P24W1

ATX workstation board for LGA 1200 Xeon and 10th Gen Core CPUs with W480 chipset, 128 GB DDR4, 2.5 GbE, dual M.2 and eight SATA ports

  • CPU Socket TypeLGA 1200
  • CPU TypeIntel Xeon W series processors 10th Generation Intel Core pr
  • ChipsetIntel W480
  • Onboard Video ChipsetIntegrated Graphics Processor-Intel HD Graphics support: 1 x
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardIntel Xeon W-1290/W-1270 series processors / Intel Core i9/i
  • Supports Xeon W and 10th Gen Core CPUs via LGA 1200 socket
  • Dual-channel DDR4 up to 128 GB with ECC on Xeon processors
  • Two M.2 slots for 2280 or 22110 drives with PCIe x4 or SATA
  • Intel 2.5 GbE LAN plus Realtek ALC1220-VB audio with 7.1-channel output
  • Triple 4K display via HDMI 1.4 and dual DisplayPort 1.4 with HDR

Workstation board for Xeon and 10th Gen Core

The GIGABYTE W480 VISION W uses the Intel W480 chipset and an LGA 1200 socket. It accepts Intel Xeon W series processors plus 10th Generation Core, Pentium and Celeron CPUs. Four DDR4 slots support up to 128GB in dual-channel mode. ECC unbuffered DIMMs are supported when a Xeon processor is installed.

Video outputs and storage for content creators

Integrated graphics drive one HDMI 1.4 port at 4096x2160@30 Hz and two DisplayPort 1.4 connections at 4096x2304@60 Hz, allowing up to three displays simultaneously. Storage includes eight SATA 6Gb/s ports, two additional SATA ports for AHCI only, plus two M.2 sockets accepting 2280 or 22110 drives with PCIe x4/x2 or SATA signalling. Intel Optane memory is supported.

Check CPU cooler clearance and power phase needs

The ATX form factor fits standard cases but verify cooler clearance around the socket area before ordering. Confirm your power supply provides the necessary EPS connectors for the chosen Xeon or Core processor. Ensure the chassis has enough SATA ports or M.2 slots to match the board's eight SATA and two M.2 connectors.

Highlights

  • Supports Xeon W and 10th Gen Core CPUs via LGA 1200 socket
  • Dual-channel DDR4 up to 128 GB with ECC on Xeon processors
  • Two M.2 slots for 2280 or 22110 drives with PCIe x4 or SATA
  • Intel 2.5 GbE LAN plus Realtek ALC1220-VB audio with 7.1-channel output
  • Triple 4K display via HDMI 1.4 and dual DisplayPort 1.4 with HDR

Specifications

BrandGIGABYTE
ModelW480 VISION W
CPU Socket TypeLGA 1200
CPU TypeIntel Xeon W series processors
10th Generation Intel Core processors / Intel Pentium processors/Intel Celeron processors
ChipsetIntel W480
Onboard Video ChipsetIntegrated Graphics Processor-Intel HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
2 x DisplayPorts, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
Support for up to 3 displays at the same time
Maximum shared memory of 512MB
Number of Memory Slots4x288pin (DDR4)
Memory StandardIntel Xeon W-1290/W-1270 series processors / Intel Core i9/i7 processors:
Support for DDR4 2933/ 2666/ 2400/ 2133 MHz
Intel Xeon W-1250 series processors / Intel Core i5/i3/Pentium/Celeron processors:
Support for DDR4 2666/ 2400/ 2133 MHz
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
* To support ECC, you must install an Intel Xeon processor.
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
* The PCIEX4_2 slot shares bandwidth with the M2M_SB connector. The PCIEX4_2 slot becomes unavailable when a device is installed in the M2M_SB connector.
PCI Express x11 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
Other Slots1 x M.2 Socket 1 connector for an Intel CNVi wireless module only (CNVI)
Serial ATA (SATA)8 x SATA 6Gb/s connectors (SATA3 0~7)
2 x SATA 6Gb/s connectors (GSATA3 0~1), supporting AHCI mode only
M.21 x M.2 connector (Socket 3, M key, type 2280/22110 PCIe x4/x2 SSD support) (M2A_CPU)
1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe x4/x2 SSD support) (M2M_SB)
Intel Optane ReadyYes
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC1220-VB codec
* The back panel line out jack supports DSD audio.
Audio Channels2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN ChipsetIntel 2.5GbE LAN chip
Second LAN ChipsetIntel GbE LAN chip
Max LAN Speed2.5Gbps + 1Gbps
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x HDMI port
2 x DisplayPorts
1 x USB 3.2 Gen 2 Type-A port (red)
3 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
2 x RJ-45 ports
1 x optical S/PDIF Out connector
5 x audio jacks
Onboard USB1 x USB 3.2 Gen 1 port (USB30_OB)
1 x USB Type-C header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x PMBUS (Power Information Detection) header
2 x SATA DOM power connectors
2 x SATA detection headers
1 x CPU fan header
1 x water cooling CPU fan header
2 x system fan headers
2 x system fan/water cooling pump headers
1 x front panel header
1 x front panel audio header
2 x Thunderbolt add-in card connectors
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
2 x serial port headers
2 x temperature sensor headers
1 x power button
1 x reset button
1 x Clear CMOS button
1 x Clear CMOS jumper
1 x Q-Flash Plus button
Form FactorATX
Dimensions (W x L)12.0" x 9.6"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
FeaturesMulti-Graphics Technology:
Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies
I/O Controller:
iTE I/O Controller Chip
H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
BIOS:
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features:
Support for APP Center
* Available applications in APP Center may vary by motherboard model. S

Questions about this item

Which processors are compatible with the LGA 1200 socket on this board?

The socket accepts Intel Xeon W series processors plus 10th Generation Intel Core, Pentium and Celeron CPUs.

What is the maximum memory capacity and which DDR4 speeds are supported?

Four DDR4 slots support up to 128 GB total; speeds reach 2933 MHz with Xeon W-1290 or W-1270 and Core i9 or i7, and 2666 MHz with other supported CPUs.

Can I run three displays from the onboard graphics outputs?

Yes, the HDMI 1.4 port and two DisplayPort 1.4 connectors can drive up to three monitors simultaneously.
