ATX motherboard with silver heatsinks and black PCB

GIGABYTE

GIGABYTE X870 AORUS ELITE WIFI7 AMD motherboard FF4D516G6000HC38ADC01

SKU CH-HPWC-AHRTC MPN FF4D516G6000HC38ADC01

ATX board for AMD Ryzen processors with DDR5 memory up to 256 GB, PCIe 5.0 graphics slot, four M.2 sockets, dual USB4, Wi-Fi 7 and 2.5 GbE LAN

  • CPU Socket TypeAM5
  • CPU TypeRyzen Series
  • ChipsetAMD X870
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardDDR5 5200
  • Maximum Memory Supported256GB
  • Supports AMD Ryzen 9000, 8000 and 7000 series processors via AM5 socket
  • 16+2+2 phase power design delivers stable voltage for high-core-count CPUs
  • Four DDR5 DIMM slots with EXPO support up to 256 GB capacity
  • PCIe 5.0 x16 graphics slot plus four M.2 connectors for fast storage
  • Wi-Fi 7 and 2.5 GbE LAN provide high-speed wired and wireless networking

AMD X870 ATX motherboard for Ryzen 9000 8000 7000

The GIGABYTE X870 AORUS ELITE WIFI7 uses the AM5 socket and AMD X870 chipset. It supports Ryzen 9000, Ryzen 8000 and Ryzen 7000 processors. Four 288-pin DDR5 slots accept up to 256 GB in dual-channel mode. The board includes one PCIe 5.0 x16 slot from the CPU and a second PCIe 4.0 x4 slot from the chipset.

Builders who want PCIe 5.0 storage and Wi-Fi 7

This board suits users who need four M.2 slots, dual USB4 ports and 2.5 Gbps Ethernet. The Realtek ALC1220 codec delivers 7.1-channel audio. Builders who require ECC memory, more than four SATA ports or a smaller form factor should consider other options.

Tool-free latches simplify installation

M.2 EZ-Latch and PCIe EZ-Latch let you fit drives and graphics cards without screws. Wi-Fi EZ-Plug makes antenna attachment straightforward. The EZ-Debug Zone helps identify boot issues. Remember that M2B_CPU and M2C_CPU share bandwidth with the primary PCIe 5.0 x16 slot, and the chipset PCIe x4 slot is disabled when M2D_SB is populated.

Highlights

  • Supports AMD Ryzen 9000, 8000 and 7000 series processors via AM5 socket
  • 16+2+2 phase power design delivers stable voltage for high-core-count CPUs
  • Four DDR5 DIMM slots with EXPO support up to 256 GB capacity
  • PCIe 5.0 x16 graphics slot plus four M.2 connectors for fast storage
  • Wi-Fi 7 and 2.5 GbE LAN provide high-speed wired and wireless networking

Specifications

BrandGIGABYTE
ModelX870 AORUS ELITE WIFI7
CPU Socket TypeAM5
CPU TypeRyzen Series
ChipsetAMD X870
Number of Memory Slots4x288pin (DDR5)
Memory StandardDDR5 5200
Maximum Memory Supported256GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
Buffer SupportedUn-buffered
Memory FeatureSupport for DDR5 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
PCI Express 5.0 x161 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x16 mode
* The M2B_CPU and M2C_CPU connectors share bandwidth with the PCIEX16 slot.
When the M2B_CPU or M2C_CPU connector is populated, the PCIEX16 slot operates at up to x8 mode.
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
(The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.)
PCI Express x4Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the M2D_SB connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2D_SB connector.
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 (PCIEX2)
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
* The M2B_CPU and M2C_CPU connectors become unavailable when an AMD Ryzen 8000 Series-Phoen
SATA RAID0/1/10
Audio ChipsetRealtek ALC1220
Audio Channels7.1 Channels
Max LAN Speed2.5Gbps
Wireless LANWi-Fi 802.11 be
BluetoothBLUETOOTH 5.4
Back I/O Ports1 x Q-Flash Plus button
1 x HDMI port
2 x antenna connectors (2T2R)
2 x USB4 USB Type-C ports (DisplayPort)
2 x USB 3.2 Gen 2 Type-A ports (red)
4 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
1 x optical S/PDIF Out connector
2 x audio jacks
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 2x2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
Other Connectors1 x CPU fan header
1 x CPU fan/water cooling pump header
4 x system fan headers
2 x system fan/water cooling pump headers
3 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
4 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x noise detection header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x HDMI port
1 x power button
1 x reset button
2 x temperature sensor headers
1 x reset jumper
1 x Clear CMOS jumper
Form FactorATX
Dimensions (W x L)12.0" x 9.6"
Power Pin1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
BIOS Feature1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
SoftwareNorton Internet Security (OEM version)
LAN bandwidth management software
Windows 11Supported
FeaturesSupport for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus
Support Smart Backup

Questions about this item

Which DDR5 memory speed and capacity does the X870 AORUS ELITE WIFI7 require for the system to post?

The board supports DDR5 modules from 4800 MT/s up to 8000 MT/s (OC) across four slots, with a maximum of 256 GB in dual-channel mode.

Will a PCIe 4.0 graphics card run at full speed in the primary PCIe 5.0 x16 slot on this motherboard?

Yes, a PCIe 4.0 card operates at its native x16 bandwidth in the CPU-linked PCIEX16 slot; the slot is backward compatible.

How can I confirm the Wi-Fi 7 and 2.5 GbE LAN are active after building the system?

Check Device Manager for the Wi-Fi 7 adapter and the 2.5 GbE controller, then verify link speed in the network status window.
