White Micro-ATX board with silver VRM heatsinks and four black DDR5 slots

GIGABYTE

GIGABYTE X870M AORUS ELITE WIFI7 ICE AMD motherboard

SKU CH-RPG5-7S28N

Micro-ATX AM5 board with 14+2+2 phase VRM, DDR5 to 8200 MT/s, Wi-Fi 7, USB4 Type-C and screwless PCIe and M.2 latches

  • Supports Ryzen 9000, 8000 and 7000 series CPUs on AM5 socket
  • DDR5 overclocking up to 8200 MT/s with EXPO and XMP profiles
  • 14+2+2 phase digital twin VRM for stable power delivery
  • Four DDR5 slots allow up to 256 GB system memory
  • WiFi 7 EZ-Plug antenna for quick wireless setup

AM5 Micro-ATX for Ryzen 9000/8000/7000

This GIGABYTE X870 board targets builders who want a compact AM5 platform with high memory headroom and integrated USB4 video. It suits gaming rigs or workstations that fit a Micro-ATX case and need up to 256 GB of DDR5. Buyers who want more storage lanes or a full-size ATX layout should look elsewhere.

DDR5 up to 8200 MT/s and 256 GB capacity

Four DIMM slots accept non-ECC unbuffered modules up to 64 GB each, running dual-channel at speeds from 4400 to 8200 MT/s via EXPO or XMP profiles. The 14+2+2 phase digital VRM delivers clean power for memory overclocking. Headroom ends at the rated 8200 MT/s ceiling and the 256 GB total limit.

USB4 Type-C with 3840x2160 DisplayPort output

Two USB4 ports driven by an ASMedia controller provide video and data through the CPU integrated Radeon graphics. Maximum resolution is 3840x2160 at 60 Hz. This single spec decides if the board meets your display connectivity needs without a discrete GPU.

Highlights

  • Supports Ryzen 9000, 8000 and 7000 series CPUs on AM5 socket
  • DDR5 overclocking up to 8200 MT/s with EXPO and XMP profiles
  • 14+2+2 phase digital twin VRM for stable power delivery
  • Four DDR5 slots allow up to 256 GB system memory
  • WiFi 7 EZ-Plug antenna for quick wireless setup

Specifications

No published specifications for this item yet.

Questions about this item

Will the 14+2+2 phase VRM handle a Ryzen 9000 series CPU alongside my existing DDR5 memory?

The board supports AMD Ryzen 9000, 8000 and 7000 series processors with a digital twin 14+2+2 phase VRM. Memory runs at DDR5 speeds up to 8200 MT/s overclocked, so your current modules will work at their rated speed or the board's maximum, whichever is lower.

How do I verify the WIFI7 module and USB4 ports are active after first boot?

Enter the BIOS and confirm the Wi‑Fi controller appears under onboard devices. In Windows, open Device Manager and check Network adapters for the WIFI7 entry and USB controllers for the two USB4 Type‑C ports showing 3840x2160 video capability.

Does the box include the WIFI EZ‑Plug antenna and M.2 screwless standoffs, or must I buy them separately?

The WIFI EZ‑Plug antenna is included for quick Wi‑Fi installation. EZ‑Latch quick‑release mechanisms are built into the PCIe and M.2 slots, so no separate screws or standoffs are required for M.2 drives.
