Rectangular ATX motherboard, dark PCB with silver heatsinks and black slots

GIGABYTE

GIGABYTE Z370 AORUS Gaming 3 Intel motherboard

SKU CH-WJ26-D1KJ9

LGA 1151 ATX board with Intel Z370 chipset, four DDR4 slots for 64GB, one PCI Express x16 slot, six SATA ports, dual M.2, Realtek ALC1220 audio and Killer E2500 LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeSupport LGA1151 slot 8th generation processor: Intel Core ™
  • ChipsetIntel Z370
  • Maximum Memory Supported64GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID2XM.2 interface, 6xSATA III interface
  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Up to 64 GB DDR4 memory across four DIMM slots
  • Realtek ALC1220 audio with 7.1-channel and S/PDIF output
  • Killer E2500 LAN delivers 1000 Mbit wired networking
  • USB 3.1 Gen 2 Type-C and Type-A ports on rear I/O

LGA 1151 Z370 ATX board

This GIGABYTE Z370 AORUS Gaming 3 motherboard accepts 8th generation Intel Core i7, i5 and i3 processors in an LGA 1151 socket. Four DDR4 DIMM slots support up to 64GB of system memory. The ATX form factor measures 30.5 by 24.4 centimetres.

PCIe x16 and storage interfaces

A single PCI Express x16 slot runs at x16 electrical specification for graphics cards. Six SATA III ports and two M.2 interfaces provide internal storage connectivity. The onboard Killer E2500 network controller handles 10, 100 and 1000 Mbit wired links.

Rear I/O and audio layout

The rear panel includes one USB Type-C port and one red USB Type-A port running at USB 3.1 Gen 2, plus additional USB 3.1 Gen 1 Type-C and Type-A ports from the chipset. Realtek ALC1220 audio supports 7.1 channel output with S/PDIF. The box contains the board, I/O shield, one SATA cable and the metal battery.

Highlights

  • Supports 8th Gen Intel Core processors via LGA 1151 socket
  • Up to 64 GB DDR4 memory across four DIMM slots
  • Realtek ALC1220 audio with 7.1-channel and S/PDIF output
  • Killer E2500 LAN delivers 1000 Mbit wired networking
  • USB 3.1 Gen 2 Type-C and Type-A ports on rear I/O

Specifications

BrandGIGABYTE
SeriesGIGABYTE Z370 AORUS Gaming 3
ModelGIGABYTE Z370 AORUS Gaming 3
CPU Socket TypeLGA 1151
CPU TypeSupport LGA1151 slot 8th generation processor: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor ®®®
2. L3 cache depends on CPU
ChipsetIntel Z370
Maximum Memory Supported64GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
3. 4 PCI Express x1 slots
* Since PCIEX4 slots share bandwidth with PCIEX1_2/3/4 slots, PCIEX4 slots operate at up to x1 bandwidth when expansion cards are installed in PCIEX1_2/3/4 slots. (All PCI Express slots support PCI Express 3.0)
SATA RAID2XM.2 interface, 6xSATA III interface
Audio Chipset1. Built-in Realtek ALC1220 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
4. Support S/PDIF output
LAN ChipsetBuilt-in Rivet Networks Killer ™ E2500 network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset + ASMedia USB 3.1 Gen 2 controller: ®
1 USB Type-C ™ interface on the rear panel, supporting USB 3.1 Gen 2
2.1 USB 3.1 Gen 2 Type-A interface (red) on the rear panel
Built-in chipset:
3. 1 USB Type-C ™ interface, support USB 3.1 Gen 1, need to be connected from the USB socket in the main board through the cable
4.6 USB 3.1 Gen 1 ports (4 on the rear panel, 2 to be connected from the USB socket in the main board via cable)
5.6 USB 2.0/1 ports (2 on the rear panel, 4 to be connected from the USB socket in the main board via cable)

Questions about this item

Should I pick the 64GB DDR4 version or a lower-capacity kit for this Z370 board?

The board supports up to 64GB across four DDR4 DIMM slots, so a 64GB kit fills every slot and gives the maximum the chipset allows.

What does the 1000 Mbit LAN figure mean once the board is in a working PC?

The Killer E2500 controller tops out at 1000 Mbit, so real-world throughput will not exceed a gigabit connection even if your router is faster.

How fast can the USB 3.1 Gen 2 Type-C port on the rear panel actually run?

The ASMedia controller drives that port at USB 3.1 Gen 2 speeds, so the practical ceiling is the Gen 2 10 Gbit/s signalling rate.
