Black rectangular ATX motherboard with silver heatsinks and four DDR4 slots

GIGABYTE

GIGABYTE Z490 GAMING X AX Intel motherboard

SKU CH-BX53-EARJ6

Supports 10th Gen Intel Core CPUs on LGA 1200 with dual-channel DDR4 up to 128 GB, two M.2 slots, WiFi 6, Bluetooth 5 and 1 GbE LAN

  • CPU Socket TypeLGA 1200
  • CPU TypeSupport for 10th Generation Intel Core i9 processors/Intel C
  • ChipsetIntel Z490
  • Onboard Video ChipsetIntegrated Graphics Processor-Intel HD Graphics support: 1 x
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardIntel Core i9/i7 processors: DDR4 4600(O.C.)/ 4500(O.C.)/ 44
  • Supports 10th Gen Intel Core i9/i7/i5/i3 processors via LGA 1200 socket
  • 11+1 phase digital VRM with DrMOS and extended heatsink for stable power delivery
  • DDR4 memory up to 4600 MHz overclocked across four slots, 128 GB maximum
  • Dual M.2 slots with PCIe 4.0-grade design and one Thermal Guard for fast storage
  • Intel WiFi 6, Bluetooth 5, and Intel GbE LAN for reliable connectivity

Z490 ATX Motherboard for 10th Gen Intel

The GIGABYTE Z490 GAMING X AX is an ATX board built for 10th generation Intel Core i9, i7, i5, i3, Pentium and Celeron processors in the LGA1200 package. It uses the Intel Z490 chipset and provides four DDR4 slots for dual channel memory up to 128GB. Integrated Intel HD Graphics are served by one HDMI 1.4 port with HDCP 2.3 support at 4096x2160 resolution and 30 Hz refresh.

PCIe 3.0 Lanes and M.2 Constraints

The primary PCI Express 3.0 x16 slot runs at x16 and a second x16 sized slot runs at x4, while three x1 slots complete the layout. Two M.2 sockets accept 2242, 2260, 2280 and 22110 form factors with both SATA and PCIe x4 or x2 signalling. Six SATA 6Gb/s ports support RAID 0, 1, 5 and 10 and the platform is Intel Optane Ready for caching acceleration.

Pre Mounted I/O Shield and Q Flash Plus

A pre installed I/O shield removes the risk of forgotten installation and the Q Flash Plus button updates the BIOS without a CPU, memory or graphics card fitted. Rear USB includes one 3.2 Gen2 Type A, five 3.2 Gen1 and two 2.0 ports, while front headers add two 3.2 Gen1 and two 2.0 connections. Networking uses Intel GbE LAN at 1Gbps plus WiFi 6 and Bluetooth 5.

Highlights

  • Supports 10th Gen Intel Core i9/i7/i5/i3 processors via LGA 1200 socket
  • 11+1 phase digital VRM with DrMOS and extended heatsink for stable power delivery
  • DDR4 memory up to 4600 MHz overclocked across four slots, 128 GB maximum
  • Dual M.2 slots with PCIe 4.0-grade design and one Thermal Guard for fast storage
  • Intel WiFi 6, Bluetooth 5, and Intel GbE LAN for reliable connectivity

Specifications

BrandGIGABYTE
ModelZ490 GAMING X AX
CPU Socket TypeLGA 1200
CPU TypeSupport for 10th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors / Intel Pentium processors/Intel Celeron processors in the LGA1200 package
ChipsetIntel Z490
Onboard Video ChipsetIntegrated Graphics Processor-Intel HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
Maximum shared memory of 512MB
Number of Memory Slots4x288pin (DDR4)
Memory StandardIntel Core i9/i7 processors:
DDR4 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2933/ 2800/ 2666/ 2400/ 2133 MHz memory modules
Intel Core i5/i3/Pentium/Celeron processors:
Support for DDR4 2666/ 2400/ 2133 MHz memory modules
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4
PCI Express x13 x PCI Express x1 slots
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A_SB)
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2M_SB)
Intel Optane ReadyYes
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC1200
Audio Channels2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN ChipsetIntel GbE LAN chip
Max LAN Speed1Gbps
Wireless LANIntel Wi-Fi 6 AX201
WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
BluetoothBLUETOOTH 5
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x HDMI port
2 x SMA antenna connectors (2T2R)
1 x USB 3.2 Gen 2 Type-A port (red)
5 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks
Onboard USB1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x CPU fan header
4 x system fan headers
2 x addressable LED strip headers
2 x RGB LED strip headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
2 x Thunderbolt add-in card connectors
1 x serial port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button
Windows 11Supported
Form FactorATX
LED LightingRGB
Dimensions (W x L)12.0" x 9.1"
Power Pin1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x 8-pin ATX 12V power connector
FeaturesMulti-Graphics Technology:
Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies
I/O Controller:
iTE I/O Controller Chip
H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS:
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features:
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported fu

Questions about this item

Should I pick the version with one M.2 slot or the version with two M.2 slots?

This model has two M.2 connectors: one supports type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSDs, the other supports type 2242/2260/2280 SATA and PCIe x4/x2 SSDs.

What does the DDR4 4600(O.C.) figure mean once the board is in a real machine?

With a 10th Gen Core i9 or i7 installed, the memory controller can run DDR4 modules up to 4600 MHz when overclocked; lower-tier CPUs top out at 2666 MHz without overclocking.

Which Wi-Fi standard is onboard and what speed does it cap at in practice?

The board includes Intel WiFi 6 and Bluetooth 5; WiFi 6 can reach multi-gigabit throughput in typical conditions, while the wired Intel GbE LAN is limited to 1 Gbps.
