Black ATX motherboard with silver LGA 1700 socket four DDR5 slots six SATA ports and metal I/O shield

GIGABYTE

GIGABYTE Z690 UD LGA 1700 Intel Z690 DDR5 192GB ATX Intel motherboard

SKU CH-SJVW-KWD5E

An ATX board with an LGA 1700 socket for 12th, 13th and 14th generation Intel CPUs, Intel Z690 chipset, four DDR5 slots supporting up to 192 GB, a PCIe x16 slot, six SATA ports, two M.2 interfaces.

  • CPU Socket TypeLGA 1700
  • CPU TypeLGA1700 slot supports 12th, 13th, 14th generation Intel ® Co
  • ChipsetIntel Z690
  • Maximum Memory Supported192GB
  • PCI Slots1 PCI-E x16 slot, supporting x16 operating specification (PC
  • SATA RAID2XM.2 interface, 6xSATA III interface
  • Supports 12th, 13th and 14th generation Intel Core processors via LGA 1700 socket
  • Up to 192GB DDR5 memory across four DIMM slots for high-capacity workloads
  • Intel Z690 chipset provides 2.5GbE LAN and USB 3.2 Gen 2x2 Type-C connectivity
  • Six SATA III ports and two M.2 interfaces give flexible storage expansion
  • Realtek audio chipset delivers 7.1-channel high-definition sound output

Z690 UD DDR5 motherboard for 12th 13th 14th

The board uses the Intel Z690 chipset and an LGA 1700 socket that accepts 12th 13th and 14th generation Core Pentium and Celeron processors. Four DDR5 DIMM slots support up to 192GB of system memory. A single PCI Express x16 slot runs at x16 electrical for the primary graphics card. The ATX form factor measures 30.5 by 24.4 centimetres.

Sustained-load behaviour with VRM and thermal design

The voltage regulator module delivers stable power to 12th 13th and 14th generation CPUs during extended workloads. Heatsinks on the VRM area dissipate heat without active cooling so clock speeds remain consistent over long sessions. The PCB uses a multi-layer layout that spreads thermal load evenly across the board. Realtek 2.5GbE LAN and integrated audio maintain throughput without throttling when the system runs hot.

192GB DDR5 capacity ceiling

Maximum supported memory is 192GB across the four DDR5 slots which determines whether the platform can handle large datasets or heavy multitasking. Populating all slots with high-capacity modules reaches this limit and enables the full benefit of the Z690 memory controller. If the intended workload needs more than 192GB this board cannot satisfy it.

Highlights

  • Supports 12th, 13th and 14th generation Intel Core processors via LGA 1700 socket
  • Up to 192GB DDR5 memory across four DIMM slots for high-capacity workloads
  • Intel Z690 chipset provides 2.5GbE LAN and USB 3.2 Gen 2x2 Type-C connectivity
  • Six SATA III ports and two M.2 interfaces give flexible storage expansion
  • Realtek audio chipset delivers 7.1-channel high-definition sound output

Specifications

BrandGIGABYTE
SeriesGIGABYTE Z690 UD
ModelGIGABYTE Z690 UD
CPU Socket TypeLGA 1700
CPU TypeLGA1700 slot supports 12th, 13th, 14th generation Intel ® Core ™/Pentium ® Gold/® Celeron ® processors
2. L3 cache depends on CPU
ChipsetIntel Z690
Maximum Memory Supported192GB
PCI Slots1 PCI-E x16 slot, supporting x16 operating specification (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
(PCIEX16 slot supports PCI-E 5.0)
2. 1 PCI-E x16 slot, supporting x4 operating specifications (PCIEX4)
3. 1 PCI-E x16 slot with x1 operating specification (PCIEX1_4)
4. 2 PCI-E x1 slots
(PCIEX4 and PCIEX1 slots support PCI-E 3.0)
SATA RAID2XM.2 interface, 6xSATA III interface
Audio Chipset1. Integrated Realtek ® audio chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 - Channel
* To start the 7.1 channel audio output, you must enter the audio software to change the default value of "Advanced Device Settings > Playback Device". Please check the detailed setting instructions on the Gigabyte website.
4. Support S/PDIF output
LAN ChipsetIntegrated Realtek ® 2.5GbE network chip (2.5 Gbps/1 Gbps/100 Mbps)
Onboard USBBased on chipset:
1 USB Type-C ® interface in the rear window IO, supporting USB 3.2 Gen 2x2
2. 1 USB Type-C ® interface, support USB 3.2 Gen 1, need to be connected from the USB socket in the main board through the cable
3.1 USB 3.2 Gen 2 Type-A interface (red) in the rear window IO
4.6 USB 3.2 Gen 1 ports (4 in the rear window IO, 2 need to be connected from the USB socket in the main board via the cable)
Based on chipset + 2 USB 2.0 Hubs:
5.8 USB 2.0/1 interfaces (4 in the rear window IO, 4 need to be connected from the USB socket in the main board via the cable)

Questions about this item

How hot and loud does the Z690 UD run under continuous load?

The board uses a passive chipset heatsink and VRM heatsinks; no active fans are fitted, so noise stays at ambient level while heat depends on the installed CPU cooler and case airflow.

What memory kit is needed to reach the 192GB DDR5 limit?

Four DDR5 DIMMs are required; the board has four slots and supports 192GB total.

Can I keep my older SATA SSDs and 2.5GbE switch with this motherboard?

Yes, six SATA III ports and a Realtek 2.5GbE LAN port are provided for existing drives and network gear.
