Rectangular ATX motherboard with dark grey metal armour covering the VRM and M.2 slots, silver I/O shield and four black DDR5 slots

GIGABYTE

GIGABYTE Z790 AORUS PRO X Intel motherboard

SKU CH-9VJ1-EZAY1

An ATX Intel Z790 motherboard with LGA 1700 socket, four DDR5 slots up to 192 GB, five M.2 slots including one PCIe 5.0, 5 GbE LAN, Wi-Fi 7, and USB 3.2 20 Gb/s Type-C

  • CPU Socket TypeLGA 1700
  • CPU TypeSupport for the 13th, and 12th Generation Intel Core, Pentiu
  • ChipsetIntel Z790 Express Chipset
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardSupport for DDR5 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.
  • Maximum Memory Supported192GB
  • Supports 12th, 13th and 14th Gen Intel Core processors via LGA 1700 socket
  • Four DDR5 DIMM slots deliver up to 192 GB with XMP 3.0 support
  • Twin 18+1+2 phase digital VRM ensures stable power for high-end CPUs
  • Five M.2 slots including one PCIe 5.0 x4 provide ultra-fast storage options
  • 5 GbE LAN and Wi-Fi 7 give high-speed wired and wireless networking

Z790 AORUS PRO X LGA 1700 ATX Motherboard

This Intel Z790 motherboard fits the LGA 1700 socket and supports 12th, 13th and 14th Generation Core, Pentium Gold and Celeron processors. It delivers a Twin 18+1+2 phase digital VRM with advanced thermal armour and M.2 guards. The board provides four DDR5 DIMM slots, five M.2 connectors, 5GbE LAN, Wi-Fi 7 and front and rear USB 3.2 Type-C 20Gb/s ports.

Who This Suits

Enthusiasts building a high-performance DDR5 system with PCIe 5.0 graphics and storage will use the full feature set. The Q-Flash Plus button allows BIOS updates without a CPU, memory or GPU installed. Users needing only SATA storage or 1GbE networking can choose a simpler board.

Deciding Specification

Four DDR5 slots support up to 192GB total capacity with XMP 3.0 profiles reaching 8266 MT/s. This memory ceiling and speed range determine whether the platform matches the workload.

Highlights

  • Supports 12th, 13th and 14th Gen Intel Core processors via LGA 1700 socket
  • Four DDR5 DIMM slots deliver up to 192 GB with XMP 3.0 support
  • Twin 18+1+2 phase digital VRM ensures stable power for high-end CPUs
  • Five M.2 slots including one PCIe 5.0 x4 provide ultra-fast storage options
  • 5 GbE LAN and Wi-Fi 7 give high-speed wired and wireless networking

Specifications

BrandGIGABYTE
ModelZ790 AORUS PRO X
CPU Socket TypeLGA 1700
CPU TypeSupport for the 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors
ChipsetIntel Z790 Express Chipset
Number of Memory Slots4x288pin (DDR5)
Memory StandardSupport for DDR5 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
Maximum Memory Supported192GB
Channel SupportedDual Channel
Memory Feature4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
PCI Express 5.0 x16CPU:
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
* The PCIEX16 slot shares bandwidth with the M2C_CPU connectors.
The PCIEX16 slot operates at up to x8 mode when a device is installed in the M2C_CPU connector.
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
PCI Express 4.0 x16Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4_1)
PCI Express 3.0 x16Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4_2)
Serial ATA (SATA)4 x SATA 6Gb/s
M.2CPU:
- 1 x M.2 connector (Socket 3, M key, type 25110/2580 PCIe 5.0 x4/x2 SSD support) (M2C_CPU)
- 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
- 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
SATA RAIDRAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Audio ChipsetRealtek ALC1220-VB CODEC
*The back panel line out jack supports DSD audio.
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Support for S/PDIF Out
Audio Channels7.1 Channels
LAN ChipsetRealtek 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)
Max LAN Speed5Gbps
Back I/O Ports2 x USB 2.0/1.1 ports
2 x SMA antenna connectors (2T2R)
4 x USB 3.2 Gen 1 ports
1 x DisplayPort In port
1 x HDMI port
2 x USB 3.2 Gen 2 Type-A ports (red)
1 x USB Type-C port, with USB 3.2 Gen 2x2 support
1 x USB Type-C port (DisplayPort), with USB 3.2 Gen 2 support
1 x RJ-45 port
1 x optical S/PDIF Out connector
2 x audio jacks
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 2x2 support
1 x USB Type-C port (DisplayPort), with USB 2.0 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
Other Connectors1 x CPU fan header
1 x CPU fan/water cooling pump header
4 x system fan headers
2 x system fan/water cooling pump headers
3 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
5 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x noise detection header
2 x Thunderbolt add-in card connectors
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only)
1 x Q-Flash Plus button
1 x reset button
1 x reset jumper
2 x temperature sensor headers
1 x Clear CMOS jumper
Windows 11Supported
Form FactorATX
Dimensions (W x L)30.5cm x 24.4cm
Power Pin1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
FeaturesSupport for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup

Questions about this item

Will a 13th generation Intel Core processor fit this socket?

Yes, the LGA 1700 socket supports 13th and 12th generation Intel Core, Pentium Gold and Celeron processors.

How many M.2 drives can I install and which one supports the fastest speeds?

Five M.2 slots are available; one CPU-connected slot supports PCIe 5.0 x4 for the highest throughput.

Can I update the BIOS before installing a CPU and memory?

Q-Flash Plus lets you update the BIOS using only a USB drive and power, with no CPU, memory or GPU installed.
