ATX motherboard with silver heatsinks and black PCB

GIGABYTE

GIGABYTE Z790 EAGLE AX LGA 1700 Intel motherboard

SKU CH-YRNW-5JW01

ATX motherboard for Intel 13th and 14th Gen CPUs with LGA 1700 socket, four DDR5 slots up to 192 GB, PCIe 5.0 x16, three M.2 connectors, 2.5 GbE LAN and Wi-Fi 6E

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel Core 13th Gen (LGA 1700)
  • ChipsetIntel Z790
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardDDR5 5600
  • Maximum Memory Supported192GB
  • Supports 14th and 13th Gen Intel Core processors via LGA 1700 socket
  • 192 GB maximum DDR5 capacity across four 288-pin slots for heavy workloads
  • Twin 12+1+1 phase digital VRM delivers stable power for overclocking
  • PCIe 5.0 x16 slot plus two M.2 connectors for high-speed NVMe storage
  • 5 GbE LAN and Intel Wi-Fi 6E provide fast, low-latency networking

Socket and Memory

This motherboard uses the Intel LGA 1700 socket and supports 13th and 14th Gen Intel Core processors. Four 288-pin DDR5 slots run in dual channel up to 192 GB. JEDEC speeds reach 5600 MT/s and overclocked profiles scale to 7600 MT/s.

Upgrade Path

This board replaces Z790 models by adding a CPU-linked PCIe 5.0 x16 slot and a PCIe 5.0 M.2 connector. The jump is worth it when the build needs GPU bandwidth at 5.0 speeds or a CPU-attached NVMe drive at 4.0 x4.

Target Builder

The 12+1+1 phase digital VRM suits high-core-count CPUs and sustained workloads. Builders who only need SATA storage, 1 GbE networking or a smaller form factor should look at a B760 or ITX alternative.

Highlights

  • Supports 14th and 13th Gen Intel Core processors via LGA 1700 socket
  • 192 GB maximum DDR5 capacity across four 288-pin slots for heavy workloads
  • Twin 12+1+1 phase digital VRM delivers stable power for overclocking
  • PCIe 5.0 x16 slot plus two M.2 connectors for high-speed NVMe storage
  • 5 GbE LAN and Intel Wi-Fi 6E provide fast, low-latency networking

Specifications

BrandGIGABYTE
ModelZ790 EAGLE AX
CPU Socket TypeLGA 1700
CPU TypeIntel Core 13th Gen (LGA 1700)
ChipsetIntel Z790
Number of Memory Slots4x288pin (DDR5)
Memory StandardDDR5 5600
Maximum Memory Supported192GB
Channel SupportedDual Channel
Memory FeatureSupport for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600 / 5400 / 5200/ 4800/4400 MT/s memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
PCI Express 5.0 x16CPU:
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
PCI Express 4.0 x16Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
PCI Express 3.0 x16Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4)
PCI Express x1Chipset:
- 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3)
Serial ATA (SATA)4 x SATA 6Gb/s
M.2CPU:
- 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
- 1 x M.2 connectors (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
- 1 x M.2 connectors (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
SATA RAIDRAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Additional RAID ControllerRAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
Audio Channels7.1 Channels
Max LAN Speed2.5Gbps
Wireless LANWi-Fi 802.11 ax
BluetoothBLUETOOTH 5.3
Back I/O Ports1 x PS/2 keyboard/mouse port
1 x USB Type-C port, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 2 Type-A port (red)
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
2 x SMA antenna connectors (1T1R)
1 x HDMI port
1 x DisplayPort
1 x RJ-45 port
3 x audio jacks
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
Other Connectors1 x CPU fan header
1 x CPU fan/water cooling pump header
3 x system fan headers
1 x system fan/water cooling pump header
2 x addressable LED strip headers
3 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x Thunderbolt add-in card connectors
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI / GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x reset button
1 x Q-Flash Plus button
1 x reset jumper
1 x Clear CMOS jumper
Windows 11Supported
Form FactorATX
Dimensions (W x L)12.0" x 9.6"
Power Pin1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
FeaturesSupport for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup
