ATX motherboard, black PCB with silver heatsinks and blue slots

GIGABYTE

GIGABYTE Z87X-UD3H LGA 1150 Intel Z87 DDR3 32GB ATX motherboard

SKU CH-ZDCF-MSGYD

LGA 1150 ATX board with Intel Z87 chipset, four DDR3 slots for up to 32 GB, one PCI Express x16 slot, eight SATA III ports, Realtek ALC898 audio with 7.1-channel support, and Intel Gigabit LAN

  • CPU Socket TypeLGA 1150
  • CPU Type1. Support LGA1150 slot processor: Intel Core ™ i7 processor
  • ChipsetIntel Z87
  • Maximum Memory Supported32GB
  • PCI Slots1 PCI Express x16 slot, supporting x16 operating specificati
  • SATA RAID8XSATA III interface
  • Supports Intel Core i7, i5, i3, Pentium and Celeron processors via LGA 1150 socket
  • Up to 32GB DDR3 memory across four DIMM slots for multitasking headroom
  • Eight SATA III ports with RAID support for flexible storage arrays
  • Realtek ALC898 audio delivers 7.1-channel high-definition sound with S/PDIF
  • Intel Gigabit LAN provides wired 10/100/1000 Mbit network connectivity

GIGABYTE Z87X-UD3H ATX motherboard

This GIGABYTE Z87X-UD3H is an ATX motherboard built on the Intel Z87 chipset for LGA 1150 processors. It accepts Intel Core i7, i5, i3, Pentium and Celeron CPUs and supports up to 32 GB of DDR3 memory across four DIMM slots. The board provides eight SATA III ports, a Realtek ALC898 audio codec with 7.1-channel output, an Intel Gigabit LAN controller and USB 3.0 and 2.0 headers for front-panel connectivity.

Refurbished board installation notes

The unit is sold as refurbished stock graded 90% to 80% new and will show signs of previous use. It ships without original packaging and includes only the motherboard, a metal battery, one SATA cable and the rear I/O shield. Buyers must verify CPU and memory compatibility before purchase and connect front-panel USB headers manually, as cables are not supplied.

Suitable for Z87 LGA 1150 rebuilds

This board suits enthusiasts replacing a failed Z87 motherboard or building a period-correct system with existing LGA 1150 parts. It is not for buyers who need a new-in-box product with a full accessory bundle, or those who require a different socket, chipset or memory type for their current components.

Highlights

  • Supports Intel Core i7, i5, i3, Pentium and Celeron processors via LGA 1150 socket
  • Up to 32GB DDR3 memory across four DIMM slots for multitasking headroom
  • Eight SATA III ports with RAID support for flexible storage arrays
  • Realtek ALC898 audio delivers 7.1-channel high-definition sound with S/PDIF
  • Intel Gigabit LAN provides wired 10/100/1000 Mbit network connectivity

Specifications

BrandGIGABYTE
SeriesGIGABYTE Z87X-UD3H
ModelGIGABYTE Z87X-UD3H
CPU Socket TypeLGA 1150
CPU Type1. Support LGA1150 slot processor: Intel Core ™ i7 processor/Intel Core ™ i5 processor/Intel Core ™ i3 processor/Intel Pentium processor/Intel Celeron processor
2. L3 cache depends on CPU
ChipsetIntel Z87
Maximum Memory Supported32GB
PCI Slots1 PCI Express x16 slot, supporting x16 operating specifications (PCIEX16)
To maximize the performance of the graphics card, it is necessary to install it in the PCIEX16 slot when installing a graphics card.
1 PCI Express x16 slot, supporting x8 operating specifications (PCIEX8)
(PCIEX16 and PCIEX8 slots support PCI Express 3.0)
Due to the shared bandwidth between the PCIEX8 slot and the PCIEX16 slot, when installing a display card in the PCIEX8 slot, the PCIEX16 slot operates at a maximum bandwidth of x8.
3. 1 PCI Express x16 slot, supporting x4 operating specifications (PCIEX4)
* Si
SATA RAID8XSATA III interface
Audio Chipset1. Built-in Realtek ALC898 chip ®
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
4. Support S/PDIF input/output
LAN ChipsetBuilt-in Intel GbE network chip (10/100/1000 Mbit)
Onboard USBBuilt-in chipset:
1. Up to 2 USB 3.0/2 ports (need to be connected from the USB socket in the main board via the cable)
2. Up to 6 USB 2.0/1 ports (need to be connected from the USB socket in the main board via the cable)
Built-in chipset + 2 Renesas uPD720210 USB 3.0 Hub: ®
3. Support up to 8 USB 3.0/2 ports (6 on the rear panel, 2 need to be connected from the USB socket in the main board via the cable)
Please download and install the Win8 USB patch to improve USB device compatibility.

Questions about this item

How can I confirm the Realtek ALC898 audio chipset is active after installing the board?

Enter the UEFI BIOS, verify the onboard audio controller is enabled, then boot into the OS and check Device Manager for the Realtek High Definition Audio device with 7.1 channel support listed.

The listing mentions only the board, a metal battery and one SATA cable — what else must I source before building?

You will need an LGA 1150 processor, up to four DDR3 DIMMs for a maximum of 32 GB, a graphics card for the PCI Express x16 slot, storage drives for the eight SATA III ports, an ATX power supply, a case that fits the 30.5 × 24.4 cm board, and any additional USB 3.0 or 2.0 header cables for front-panel ports.

The board has four DDR3 slots supporting 32 GB total — which capacity kit should I choose?

Populate all four slots with an 8 GB DDR3 kit to reach the 32 GB limit, or use a 16 GB kit in two slots if you prefer to leave room for later expansion.
