Small green circuit board, black chips, gold edge connector

GIONEDA

GIONEDA 256GB M.2 2280 NVMe internal SSD

SKU CH-YR2J-SZQ30

A 256 GB M.2 2280 NVMe internal SSD delivering sequential reads up to 2000 MB/s and writes up to 1600 MB/s over PCIe Gen3x4 for faster boots and application loads

  • Faster boots and app loads with PCIe Gen3x4 speeds up to 2200 MB/s read and 1600 MB/s write
  • Efficient performance via NVMe 1.3, Host Memory Buffer and SLC cache technology
  • Strong data integrity with LDPC, ECC, end-to-end protection and RAID engine
  • Reliable 3D NAND flash rated for 1 million hours MTBF and 0.69 DWPD
  • Low 2.0 W max power draw runs cool from 0 °C to 70 °C

GIONEDA 256GB M.2 2280 NVMe internal SSD

This internal solid state drive fits M.2 2280 slots in laptops and desktops. It targets users who want faster boot times, quicker application launches and snappier file transfers without moving to a larger capacity. The PCIe Gen3x4 interface and NVMe 1.3 support make it a direct upgrade for systems limited to older storage protocols. Builders needing more than 256GB or a Gen4 interface should look elsewhere.

NVMe 1.3 with HMB and SLC Cache

The drive implements NVMe 1.3, Host Memory Buffer and SLC caching to sustain high throughput during everyday workloads. LDPC, ECC, end-to-end data protection and a RAID engine work together to preserve data integrity across power cycles. Sequential reads reach up to 2000 MB/s while sequential writes hit up to 1600 MB/s, with random 4K performance of 100200 IOPS read and 14500 IOPS write. No additional software bundle or hardware accessories are included in the package.

256GB capacity with 0.69 DWPD endurance

At 256GB the drive comfortably holds an operating system, core applications and a modest working set of documents or media. The 0.69 drive writes per day rating and 1 million hour MTBF provide headroom for typical client workloads over several years. Operating temperatures from 0 to 70°C and storage temperatures from -20 to 75°C cover standard indoor environments. Heavy content creation, large game libraries or sustained write-intensive server tasks will exceed the available space and endurance budget.

Highlights

  • Faster boots and app loads with PCIe Gen3x4 speeds up to 2200 MB/s read and 1600 MB/s write
  • Efficient performance via NVMe 1.3, Host Memory Buffer and SLC cache technology
  • Strong data integrity with LDPC, ECC, end-to-end protection and RAID engine
  • Reliable 3D NAND flash rated for 1 million hours MTBF and 0.69 DWPD
  • Low 2.0 W max power draw runs cool from 0 °C to 70 °C

Specifications

No published specifications for this item yet.

Questions about this item

How many drive writes per day is the 256 GB GIONEDA rated for?

The drive carries a DWPD rating of .69, meaning it is warranted for roughly 69 percent of one full drive write each day.

What limit appears first when the SSD runs a heavy workload continuously?

Sequential write speed tops out at 1600 MB/s and the controller will throttle once the drive temperature reaches 70 °C.

How much power does the M.2 2280 NVMe drive draw and how hot does it get under all-day use?

Maximum power draw is 2.0 W at 3.3 V, and the operating temperature range is 0 °C to 70 °C.
