Green M.2 2280 SSD with graphene heatsink and screw

GUDGA

GUDGA GVL-XXX-2280 512GB internal SSD

SKU CH-85EN-EARRV

M.2 2280 NVMe SSD with graphene heatsink delivers 3500 MB/s read and 2700 MB/s write for desktops and laptops

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity512GB
  • Memory Components3D TLC
  • InterfacePCI-Express 3.0 x4
  • Fast boot and load times with up to 3500MB/s sequential read
  • Responsive writes for large files at up to 2700MB/s sequential write
  • Graphene heatsink keeps temperatures steady during heavy workloads
  • 320TB written endurance rating supports long-term daily use
  • 2 million hour MTBF indicates high reliability over time

GUDGA GVL-XXX-2280 512GB NVMe SSD

The GUDGA GVL-XXX-2280 is a 512GB internal solid-state drive built in the M.2 2280 form factor. It connects through a PCI-Express 3.0 x4 interface using the NVMe protocol and uses 3D TLC NAND flash. A graphene heatsink is integrated to manage thermals during sustained workloads.

Suits builds with an M.2 slot wired for PCIe 3.0

This drive fits desktops and notebooks that provide an M.2 2280 key-M slot supporting PCI-Express 3.0 x4 NVMe. Systems limited to PCIe 2.0 or earlier will not reach the rated speeds. Buyers needing higher endurance or PCIe 4.0 bandwidth should consider other models.

3500 MB/s maximum sequential read speed

The headline figure is a maximum sequential read of 3500 MB/s paired with a 2700 MB/s maximum sequential write. Endurance is rated at 320 TBW with an MTBF of 1,200,000 hours. If your workload demands sustained throughput above these numbers, a faster drive is required.

Highlights

  • Fast boot and load times with up to 3500MB/s sequential read
  • Responsive writes for large files at up to 2700MB/s sequential write
  • Graphene heatsink keeps temperatures steady during heavy workloads
  • 320TB written endurance rating supports long-term daily use
  • 2 million hour MTBF indicates high reliability over time

Specifications

BrandGUDGA
SeriesGVL 2280 Series
ModelGVL-XXX-2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity512GB
Memory Components3D TLC
InterfacePCI-Express 3.0 x4
ProtocolNVMe
Max Sequential Read3500MB/s
Max Sequential Write2700MB/s
Terabytes Written (TBW)320TB
MTBF1,200,000 hours
HeatSinkwith HeatSink
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +70°C
Height2.20mm
Width22mm
Depth80mm
Weight20g
Manufacturer RecertifiedYes

Questions about this item

Does the GUDGA GVL-XXX-2280 512GB SSD fit a standard M.2 2280 slot with a 2.20 mm height limit?

Yes, the drive measures 22 mm wide, 80 mm long and 2.20 mm high, matching the M.2 2280 form factor used in most desktops and laptops.

The box includes one screw — which thread size does it use and where does it go?

The supplied screw is an M2 thread that secures the drive's mounting hole to the motherboard standoff; tighten it gently after inserting the drive at a 20-degree angle.

How can I check the remaining write endurance of the 320 TBW rating over time?

Use the SMART attributes in tools such as CrystalDiskInfo or the OS disk utility to read the percentage of TBW used and the media wear indicator.
