Green rectangular micro-ATX board with silver CPU socket, two black memory slots, one long and one short expansion slot

Hoengager

Hoengager H61MATX LGA 1155 DDR3 Intel motherboard

SKU CH-4A66-59QYA

Micro-ATX board with Intel H61 chipset, LGA 1155 socket, two DDR3 slots up to 16 GB, one PCIe x16 slot, 5.1-channel audio and 100 Mbps LAN

  • CPU Socket TypeLGA 1155
  • CPU TypeCore i7 / i5 / i3 (LGA1155)
  • ChipsetIntel H61
  • Number of Memory Slots2
  • Memory StandardDDR3 1066 1333 1600
  • Maximum Memory Supported16GB
  • Supports LGA 1155 Core i7, i5, i3, Pentium, Celeron CPUs
  • Dual-channel DDR3 memory up to 16 GB at 1066, 1333, 1600
  • Micro-ATX form factor 190 mm x 170 mm fits compact builds
  • Realtek ALC662 codec delivers 5.1-channel audio
  • Four SATA 3Gb/s ports and 100 Mbps LAN for storage and networking

Intel H61 micro-ATX board for LGA 1155 CPUs

The motherboard uses the Intel H61 chipset and fits micro-ATX cases measuring 190mm by 170mm. It accepts Core i7, i5, i3, Pentium and Celeron processors in the LGA 1155 socket. Two DDR3 slots support dual-channel memory up to 16GB at 1066, 1333 or 1600 speeds.

Four SATA 3Gb/s ports and legacy expansion

Four SATA 3Gb/s connectors provide storage attachment for hard drives or SSDs. A single PCI Express x16 slot and one PCI Express x1 slot handle graphics cards and add-in boards. No M.2, mSATA or Optane interfaces are present on this board.

Realtek ALC662 5.1-channel audio

Onboard sound uses the Realtek ALC662 codec delivering 5.1-channel output. Wired networking is limited to 100Mbps Ethernet with no wireless or Bluetooth capability. The board also lacks integrated graphics, so a discrete video card is required for display output.

Highlights

  • Supports LGA 1155 Core i7, i5, i3, Pentium, Celeron CPUs
  • Dual-channel DDR3 memory up to 16 GB at 1066, 1333, 1600
  • Micro-ATX form factor 190 mm x 170 mm fits compact builds
  • Realtek ALC662 codec delivers 5.1-channel audio
  • Four SATA 3Gb/s ports and 100 Mbps LAN for storage and networking

Specifications

BrandJingsha
SeriesMicro ATX
ModelH61MATX
CPU Socket TypeLGA 1155
CPU TypeCore i7 / i5 / i3 (LGA1155)
ChipsetIntel H61
Number of Memory Slots2
Memory StandardDDR3 1066 1333 1600
Maximum Memory Supported16GB
Channel SupportedDual Channel
PCI Express x161 x PCI Express x16
PCI Express x11 x PCI Express x1
M.2Not Available
Intel Optane ReadyNot Available
mSATANot Available
Audio ChipsetRealtek ALC662
Audio Channels5.1 Channels
Max LAN Speed100Mbps
Wireless LANNot Available
BluetoothNot Available
Back I/O Ports1 x HDMI / 2 x PS/2 / 4 x USB 2.0/1.1
PS/22
Video PortsVGA + HDMI
HDMI1 x HDMI
RJ451 x RJ45
DisplayPort0
Thunderbolt Ports0
USB 3.10
USB 3.00
USB 1.1/2.04 x USB 2.0
USB Type-C0
Audio Ports3 Ports
Onboard USB4 x USB 2.0
Form FactorMicro ATX
LED LightingNo RGB
Dimensions (W x L)170mm x 190mm
Power Pin24 Pin
Package ContentsMotherboard *1 I/O Shield *1 Chinese Manual*1

Questions about this item

Will the Realtek ALC662 audio chipset need a driver update later?

The Realtek ALC662 is a mature 5.1 channel codec supported in modern Windows and Linux kernels without extra downloads.

What limits sustained load on the Intel H61 chipset?

The single PCI Express x16 slot and 100Mbps LAN cap throughput before the chipset itself becomes a bottleneck.

How much heat and power does the board draw running all day?

With no onboard video the H61 chipset and two DDR3 slots keep idle draw low; a standard 4-pin CPU fan header handles VRM airflow.
