Silver 1U rack server front panel with eight 2.5 inch drive bays

HP

HP ProLiant DL360 Gen9 1U 2× Xeon E5-2640v3 96GB DDR4 2× 146GB SAS H240ar

SKU CH-VYZ4-XZF6E

1U rack server with dual Xeon E5-2640v3 CPUs, 96GB DDR4, two 146GB 15K SAS drives and H240ar RAID controller

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Dual Xeon E5-2640v3 CPUs deliver 16 cores and 32 threads for parallel workloads
  • 96GB DDR4 ECC memory across 24 slots supports large datasets
  • Two 146GB 15K SAS drives provide fast storage access
  • H240ar controller enables RAID 0/1/5/6/10/50/60 for data protection
  • Dual 500W hot-swap power supplies keep the 1U server running

HP ProLiant DL360 Gen9 1U server

This 1U rack server ships with two Intel Xeon E5-2640v3 eight-core processors running at 2.6 GHz and 96 GB of DDR4 ECC registered memory. It includes a Smart HBA H240ar controller and two 146 GB 15K 2.5-inch SAS drives. The platform targets virtualisation hosts, database nodes and other space-constrained workloads needing dual-socket density.

Memory ceiling and drive bay limits

Installed memory already reaches the 96 GB maximum supported by this specific configuration, so no further DIMM upgrades are possible without changing the CPU specification. The chassis provides eight SFF bays in total; two are occupied by the supplied SAS drives, leaving six bays for additional 2.5-inch SAS or SATA devices. The H240ar controller handles 12 Gb SAS and 6 Gb SATA links with RAID 0, 1, 5, 6, 10, 50 and 60.

Power, rail and OS checklist

Dual 500 W hot-swap redundant power supplies are fitted; verify that your rack PDU provides matching IEC C14 inlets and sufficient circuit capacity for the pair. Confirm that your 1U rack rails accept the DL360 Gen9 chassis depth and that the Matrox G200 graphics output meets your console needs. No operating system is included, so plan your hypervisor or OS installation media and licensing before deployment.

Highlights

  • Dual Xeon E5-2640v3 CPUs deliver 16 cores and 32 threads for parallel workloads
  • 96GB DDR4 ECC memory across 24 slots supports large datasets
  • Two 146GB 15K SAS drives provide fast storage access
  • H240ar controller enables RAID 0/1/5/6/10/50/60 for data protection
  • Dual 500W hot-swap power supplies keep the 1U server running

Specifications

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size96GB
Memory TypeDDR4
Max Memory Capacity96GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose this server with 96GB DDR4 or add more memory later?

The system already reaches its installed maximum of 96GB DDR4 across 24 DIMM slots; further expansion would require replacing existing modules.

What does the 2.6GHz Xeon E5-2640v3 speed deliver in this 1U rack server?

Dual eight-core processors provide 16 physical cores and 32 threads at 2.6GHz, giving strong multi-threaded throughput for virtualisation and database workloads within a 1U form factor.

How does the H240ar controller's 12Gb SAS interface affect the 146GB 15K drives?

The controller supports 12Gb SAS, but the installed 146GB drives run at 6Gbps, so the interface caps at the drive speed rather than the controller maximum.
