Silver 1U rack server front panel with eight 2.5-inch drive bays

HP

HP ProLiant DL360 Gen9 1U rack server E5-2620 v3 2.4GHz 16GB 2x 146GB SAS H240ar

SKU CH-3BBS-AB280

1U rack server with a six-core Xeon E5-2620 v3 at 2.4 GHz, 16 GB DDR4, two 146 GB 15K SAS drives and H240ar RAID

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Dual 500W redundant power supplies keep the server running if one fails
  • Six-core Xeon E5-2620 v3 at 2.4GHz delivers 12 threads for multi-threaded workloads
  • 16GB DDR4 ECC memory protects data integrity in critical applications
  • Two 146GB 15K SAS drives provide fast, reliable storage for OS and apps
  • Smart HBA H240ar supports RAID 0, 1, 5, 6, 10, 50, 60 for flexible data protection

Compact 1U rack server for dense compute

The HP ProLiant DL360 Gen9 fits a single Intel Xeon E5-2620 v3 six-core processor at 2.4 GHz with 16 GB of DDR4 ECC memory into a 1U chassis. Dual redundant 500 W power supplies and an H240ar controller with two 146 GB 15 K SAS drives provide a ready-to-run foundation for virtualisation or database workloads. Eight small-form-factor bays allow further expansion within the same rack unit.

Suits space-constrained racks needing SAS redundancy

This server targets administrators who need high spindle speed and hardware RAID 0/1/5/6/10/50/60 in a shallow 1U envelope. Buyers who want more than eight drive bays or who require a second processor installed from the outset should look at a different chassis. The Matrox G200 graphics and single CPU configuration limit GPU-accelerated or heavily threaded tasks.

Single Xeon E5-2620 v3 six-core 2.4 GHz processor

The installed CPU delivers six physical cores and twelve threads via hyper-threading, setting the baseline for all compute capacity. Memory currently occupies a fraction of the 24 DIMM slots, so growth to larger DDR4 ECC Registered kits is possible without replacing the processor. The H240ar controller caps RAID performance at 12 Gb/s SAS and 6 Gb/s SATA.

Highlights

  • Dual 500W redundant power supplies keep the server running if one fails
  • Six-core Xeon E5-2620 v3 at 2.4GHz delivers 12 threads for multi-threaded workloads
  • 16GB DDR4 ECC memory protects data integrity in critical applications
  • Two 146GB 15K SAS drives provide fast, reliable storage for OS and apps
  • Smart HBA H240ar supports RAID 0, 1, 5, 6, 10, 50, 60 for flexible data protection

Specifications

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity16GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the server need a second Xeon processor installed before I can use all 24 DIMM slots?

The 24 DIMM slots are split 12 per processor, so the second CPU must be fitted to access the remaining 12 slots.

Will my existing 6 Gbps SAS drives run at full speed on the H240ar controller?

The H240ar supports 12 Gbps SAS and 6 Gbps SATA, so 6 Gbps SAS drives operate at their native link rate.

How can I verify the two 146 GB drives are configured as a healthy RAID 1 volume after first boot?

Enter the H240ar Option ROM during POST or use the Smart Storage Administrator to confirm the logical drive shows RAID 1 with OK status.
