Silver 1U rack server with four front drive bays and redundant power supplies

HP

HP ProLiant DL360 Gen9 1U Rack Server E5-2620 v3 2.4GHz 96GB 2x 1TB SAS

SKU CH-VP4T-TJDXB

1U rack server with a six-core Xeon at 2.4 GHz, 96 GB DDR4, two 1 TB SAS drives and redundant 500 W power supplies

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Six-core Xeon at 2.4 GHz handles multi-threaded workloads
  • 96 GB DDR4 ECC memory supports virtualisation density
  • Two 1 TB 7.2 K SAS drives provide redundant storage
  • Smart HBA H240ar enables RAID 0/1/5/6/10/50/60 flexibility
  • Dual 500 W hot-swap power supplies maintain uptime

Purpose-built density

This 1U rack server fits a dual-socket Intel Xeon E5 v3 platform, 96GB DDR4 ECC memory and two 1TB 7.2K SAS drives into a single rack unit. It targets IT teams that need maximum compute and storage density in space-constrained racks. Buyers who require more than 96GB memory or more than four 3.5-inch drive bays should look elsewhere.

Thermals and power

Dual 500W hot-swap redundant supplies share the load, keeping the system running if one unit fails. The 1U chassis uses high-speed fans that ramp with CPU and drive activity; expect noticeable airflow noise under sustained load. Power draw scales with the installed processor and drive count, so plan rack PDU capacity accordingly.

Memory ceiling

The board provides 24 DDR4 DIMM slots, 12 per processor, with a hard limit of 96GB on this configuration. Any upgrade beyond that figure requires a second processor and higher-capacity modules, so verify the maximum before purchasing additional memory.

Highlights

  • Six-core Xeon at 2.4 GHz handles multi-threaded workloads
  • 96 GB DDR4 ECC memory supports virtualisation density
  • Two 1 TB 7.2 K SAS drives provide redundant storage
  • Smart HBA H240ar enables RAID 0/1/5/6/10/50/60 flexibility
  • Dual 500 W hot-swap power supplies maintain uptime

Specifications

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size96GB
Memory TypeDDR4
Max Memory Capacity96GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install a second Xeon E5-2620 v3 processor in the 1U rack chassis?

Power down the server, remove the top cover, open the second CPU socket cover, align the processor triangle with the socket key, lower the retention lever, apply thermal paste, attach the heatsink, reconnect the fan cable, and verify detection in BIOS.

When will the 96GB DDR4 ECC registered memory need replacement?

The 24 DIMM slots are fully populated at the 96GB maximum, so no further expansion is possible; modules only require replacement if a DIMM fails or if you migrate to a platform supporting higher capacity.

At what point does the Smart HBA H240ar controller become the bottleneck under sustained write workloads?

The controller supports 12Gb SAS and 6Gb SATA links, but the installed 7.2K 6Gbps SAS drives limit sustained throughput well before the HBA reaches its own bandwidth ceiling.
