Silver 2U rack server with 24 front drive bays and redundant power supplies

HP

HP ProLiant DL380 Gen9 2U rack server E5-2643 v3 3.4 GHz 6-core 48 GB DDR4 2×1 TB SAS P440 4 GB FBWC

SKU CH-XKCF-5ZQEQ

2U rack server with a 3.4 GHz 6-core Xeon, 48 GB DDR4, two 1 TB SAS drives and a P440 4 GB FBWC RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Six-core Xeon at 3.4 GHz for high single-thread speed
  • 48 GB DDR4 ECC memory across 24 DIMM slots
  • Dual 1 TB SAS drives on P440 controller with 4 GB FBWC
  • Redundant hot-swap 500 W power supplies for uptime
  • 2U rack chassis with 24 SFF bays for dense storage

ProLiant DL380 Gen9 2U rack server

This HP ProLiant DL380 Gen9 is a 2U rack server built for data-centre workloads. It ships with a single Intel Xeon E5-2643 v3 six-core processor running at 3.4 GHz, 48 GB of DDR4 ECC memory and a Smart Array P440 controller with 4 GB flash-backed write cache. Two 1 TB 7.2K SAS drives and redundant 500 W hot-swap power supplies are included.

Virtualisation hosts and database nodes needing 24

The 24-bay SFF chassis suits teams that want dense local storage in a 2U footprint and can expand to a second Xeon for up to 36 total cores. Buyers who need more than 48 GB of installed memory or who require GPU compute density should look at a different platform. The Matrox G200eH2 graphics adapter is intended only for basic management output.

24 SFF drive bays with P440 RAID controller

The server provides 24 small-form-factor bays backed by the P440 controller supporting RAID 0, 1, 5, 6, 10, 50 and 60. This bay count and RAID flexibility determine whether the chassis can hold the local storage layout your workload demands.

Highlights

  • Six-core Xeon at 3.4 GHz for high single-thread speed
  • 48 GB DDR4 ECC memory across 24 DIMM slots
  • Dual 1 TB SAS drives on P440 controller with 4 GB FBWC
  • Redundant hot-swap 500 W power supplies for uptime
  • 2U rack chassis with 24 SFF bays for dense storage

Specifications

BrandHP
SeriesProLiant
ModelProliant DL380 G9
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size48GB
Memory TypeDDR4
Max Memory Capacity48GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart Array P440/4GB FBWC Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200eH2
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 3 PCIe 3.0 Slots (1-3) available: 2x Full-Height Half Length, 1x Half-Lenth Full Height. Optional 3 additional slots (Slot 2 PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the server ship with an operating system pre-installed?

No operating system is included; the server arrives without any OS or hypervisor installed.

The listing shows 48 GB DDR4 but the specification mentions a 3 TB maximum — which capacity should I choose?

The unit comes with 48 GB across 24 DIMM slots; add registered ECC DDR4 modules up to the 3 TB limit if the workload needs more memory.

The two 1 TB SAS drives run at 7.2K rpm — what usable capacity does RAID 1 give me?

RAID 1 mirrors the pair, so the array presents 1 TB of usable space with the second drive providing redundancy.
