Silver 2U rack server front panel with eight 2.5 inch drive bays

HP

HP ProLiant DL380 Gen9 2U Rack Server E5-2670 v3 12C 2.3GHz 16GB DDR4 2x 146GB SAS H240ar

SKU CH-6ECQ-NTD3T

2U rack server with twelve-core Xeon at 2.3 GHz, 16 GB DDR4, two 146 GB 15 K SAS drives and H240ar RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • 12-core Xeon E5-2670 v3 at 2.3GHz powers demanding workloads
  • 16GB DDR4 ECC memory supports up to 3TB across 24 DIMM slots
  • Two 146GB 15K SAS drives deliver fast storage in 2.5-inch bays
  • Smart HBA H240ar enables RAID 0/1/5/6/10/50/60 with 12Gb SAS
  • Dual 500W hot-swap power supplies provide redundant power

Built for dense compute

The HP ProLiant DL380 Gen9 is a 2U rack server equipped with a twelve-core Intel Xeon E5-2670 v3 at 2.3GHz, 16GB DDR4 ECC memory and two 146GB 15K SAS drives on an H240ar controller. Redundant 500W hot-swap power supplies and eight SFF bays suit data-centre workloads needing high core density and fast local storage.

Fits virtualisation and database tiers

Teams running hypervisors, mid-range databases or compute clusters benefit from the twelve cores with hyper-threading, RAID 0/1/5/6/10/50/60 support and room for a second processor. Buyers who need more storage than two 146GB drives, GPU acceleration or NVMe boot devices should look at configurations with additional drive cages or universal media bays.

Single-CPU limit caps memory at 16GB today

With one processor installed the board exposes twelve DIMM slots, yet the unit ships with only 16GB total. Expanding memory requires populating the remaining slots with DDR4 registered ECC modules up to 2400MT/s; the full 3TB ceiling is only reachable after adding the second CPU.

Highlights

  • 12-core Xeon E5-2670 v3 at 2.3GHz powers demanding workloads
  • 16GB DDR4 ECC memory supports up to 3TB across 24 DIMM slots
  • Two 146GB 15K SAS drives deliver fast storage in 2.5-inch bays
  • Smart HBA H240ar enables RAID 0/1/5/6/10/50/60 with 12Gb SAS
  • Dual 500W hot-swap power supplies provide redundant power

Specifications

BrandHP
SeriesProLiant
ModelProliant DL380 G9
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity16GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200eH2
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 3 PCIe 3.0 Slots (1-3) available: 2x Full-Height Half Length, 1x Half-Lenth Full Height. Optional 3 additional slots (Slot 2 PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I verify the server is running correctly after installation?

Power on the unit and watch the front-panel health LEDs; the iLO interface will report CPU, memory and drive status once the system completes POST.

What components are included and which must be purchased separately?

The chassis ships with one E5-2670 v3 processor, 16GB DDR4, two 146GB 15K SAS drives in trays, an H240ar controller and two 500W redundant supplies; operating system, additional CPUs, memory modules and extra drive trays are not included.

Which memory capacity should I select for this configuration?

The system has 24 DIMM slots supporting 4GB, 8GB, 16GB, 32GB or 64GB DDR4 ECC Registered modules up to 2400MT/s; choose modules that match the installed 16GB and the processor’s supported speed.
