Silver 2U rack server with front drive bays and power supply

HP

HP ProLiant DL380p Gen8 2U Rack Server 2 x Xeon E5-2630 2.3GHz 16GB DDR3 677278-001

SKU CH-4WRR-56QZ3 MPN 677278-001

2U rack server with dual Xeon E5-2630 2.3GHz CPUs, 16GB DDR3, 8 SFF drive bays and a 460W 94% efficient power supply

  • TypeRack
  • Rack Height2U
  • CPU Type2 x Intel Xeon E5-2630 2.3GHz 6C/12T
  • CPU Features95W
  • Cache Memory15M
  • Installed Memory Size16GB (4 x 4GB)
  • Dual Xeon E5-2630 CPUs deliver 12 total cores for multi-threaded workloads
  • 16GB DDR3 memory installed across 4 DIMM slots with 24 slots available
  • Expandable to 768GB maximum memory capacity for demanding applications
  • Smart Array P420i controller supports RAID 0/1/1+0/5/5+0 with 1GB FBWC
  • 460W Platinum Plus power supply operates at 94% efficiency with hot-plug redundancy

Dual Xeon E5-2630 2U Server

The HP ProLiant DL380p Gen8 is a 2U rackmount server system built around two Intel Xeon E5-2630 processors. Each CPU runs at 2.3 GHz with six cores and twelve threads. The chassis includes sixteen gigabytes of DDR3 memory across four modules and a Smart Array P420i controller with flash-backed write cache.

Suits Virtualisation Hosts Not High-Frequency

This platform fits teams consolidating multiple virtual machines on a two-socket box with room to grow memory to 768 GB across twenty-four slots. The 95 W processors favour throughput over single-thread speed so workloads needing maximum clock rate will not benefit. Buyers who need installed storage drives should look elsewhere as the chassis ships without hard drives.

Smart Array P420i With FBWC Decides RAID Options

The integrated HP Smart Array P420i controller provides one gigabyte of flash-backed write cache and supports RAID 0, 1, 1+0, 5 and 5+0 across SATA and SAS drives. This specification determines whether the server can meet your data-protection and performance requirements without adding a separate controller card.

Highlights

  • Dual Xeon E5-2630 CPUs deliver 12 total cores for multi-threaded workloads
  • 16GB DDR3 memory installed across 4 DIMM slots with 24 slots available
  • Expandable to 768GB maximum memory capacity for demanding applications
  • Smart Array P420i controller supports RAID 0/1/1+0/5/5+0 with 1GB FBWC
  • 460W Platinum Plus power supply operates at 94% efficiency with hot-plug redundancy

Specifications

BrandHP
SeriesProLiant DL380p Gen8
Model677278-001
TypeRack
Rack Height2U
CPU Type2 x Intel Xeon E5-2630 2.3GHz 6C/12T
CPU Features95W
Cache Memory15M
Installed Memory Size16GB (4 x 4GB)
Memory TypeDDR3
Max Memory Capacity768GB
Memory Features24 DIMM slots
Advanced ECC
Online Spare
Hard Drive (Installed)No Hard Drive
Storage ControllerHP Smart Array P420i/1GB with FBWC
HDD InterfaceSATA/SAS
Raid LevelRAID 0/1/1+0/5/5+0
Ethernet ControllerHP Ethernet 1Gb 4-port 331FLR Adapter
Expansion Slots3 PCIe slots (+3 PCI slots available with upgrade option)
Expansion BaysStandard: 8 SFF SAS/SATA HDD Bays
Power Characteristics(1) 460W HP CS Platinum Plus Hot Plug Power Supply (94% Efficient)
FeaturesFans: (6) (N+1 redundancy standard)
Management: iLO Management Engine Standard
Dimensions3.44" x 17.54" x 27.50"
Package ContentsHP 677278-001 Brand New Chassis - Product Warranty: HP 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
Shipping weight13.61 kg
Package size762 × 508 × 254 mm

Questions about this item

Do I need to buy SAS or SATA drives separately because the server ships with no hard drive installed?

Yes, the unit arrives with zero drives fitted; you must supply 2.5-inch SAS or SATA drives for the eight SFF bays.

Will my existing PCIe 2.0 expansion cards work in the three PCIe slots?

The three PCIe slots accept PCIe 2.0 and 3.0 cards, so older PCIe 2.0 adapters will function normally.

How can I confirm the Smart Array P420i controller is healthy after installation?

During POST the P420i reports its 1 GB FBWC status, and the iLO interface shows controller firmware version and battery health.
