Silver 2U rack server front panel with drive bays and DVD drive

HP

HP ProLiant DL380p Gen8 709943-001 2U rack server 2× Xeon E5-2690 v2 3.0GHz 10-core 32GB DDR3

SKU CH-FWZV-Z4VZQ MPN 709943-001

Two-socket rack server with dual Xeon E5-2690 v2 processors, 32 GB DDR3 memory and a Smart Array P420i controller with 2 GB flash-backed write cache

  • TypeRack
  • Rack Height2U
  • CPU TypeIntel Xeon
  • CPU Features(2) Intel® Xeon® E5-2690 v2 (3.0GHz/10-core/25MB/8.0GT-s QPI
  • MAX Processors2
  • Installed Memory Size32GB
  • Dual 10-core Xeon E5-2690 v2 at 3.0GHz for multi-threaded throughput
  • 32GB DDR3 installed across 24 slots with 384GB maximum capacity
  • Smart Array P420i with 2GB FBWC supporting RAID 0/1/5/6/10
  • FlexFabric 10Gb dual-port 533FLR-T adapter for high-speed networking
  • Dual 750W 94% efficient hot-plug power supplies for redundancy

Dual Xeon E5-2690 v2 server

The HP ProLiant DL380p Gen8 709943-001 is a 2U rack-mount system built for organisations that need dense compute in a standard cabinet. It ships with two Xeon E5-2690 v2 processors, each running at 3.0GHz with 10 cores and 25MB cache. The platform supports a maximum of two processors and provides 24 DDR3 memory slots for expansion.

Sustained load behaviour

Each CPU carries a 130W thermal design, so the pair draws significant power under continuous multi-threaded workloads. The unit includes two 750W Platinum Plus hot-plug supplies rated at 94% efficiency to maintain stable delivery during extended runs. DDR3-1866 memory operates at 8.0GT/s QPI to keep data moving between sockets without throttling.

Practical interface limits

Storage connects through a Smart Array P420i controller with 2GB flash-backed write cache, supporting RAID 0, 1, 1+0, 5, 5+0, 6 and 6+0 across SATA and SAS drives. The six 2.5-inch hot-swap bays accept SFF media only. Networking is handled by a FlexFabric 10Gb two-port 533FLR-T adapter, while expansion is limited to six slots and graphics output uses the onboard Matrox G200 controller.

Highlights

  • Dual 10-core Xeon E5-2690 v2 at 3.0GHz for multi-threaded throughput
  • 32GB DDR3 installed across 24 slots with 384GB maximum capacity
  • Smart Array P420i with 2GB FBWC supporting RAID 0/1/5/6/10
  • FlexFabric 10Gb dual-port 533FLR-T adapter for high-speed networking
  • Dual 750W 94% efficient hot-plug power supplies for redundancy

Specifications

BrandHP
SeriesProLiant DL380p Gen8
Model709943-001
TypeRack
Rack Height2U
CPU TypeIntel Xeon
CPU Features(2) Intel® Xeon® E5-2690 v2 (3.0GHz/10-core/25MB/8.0GT-s QPI/130W, DDR3-1866, HT)
MAX Processors2
Installed Memory Size32GB
Max Memory Capacity384GB
Memory FeaturesMemory Technology:DDR3 SDRAM
Number of Memory Slots24
Hard Drive (Installed)None ship standard; includes 6 SFF hard drive blanks
Storage ControllerHP Smart Array P420i/2GB FBWC (RAID 0/1/1+0/5/5+0/6/6+0)
HDD InterfaceSATA/SAS
Raid LevelRAID 0/1/1+0/5/5+0/6/6+0
Media DrivesDVD +/- RW
GPU TypeGraphics Controller Manufacturer Matrox Graphics Controller Model G200
Ethernet ControllerHP FlexFabric 10Gb 2-port 533FLR-T Adapter
Expansion Slots6
Expansion Bays8 SFF SAS/SATA HDD Bays; Optional: +8 SFF (total of 16)
Power Characteristics(2) HP 750W CS Platinum Plus Hot Plug Power Supply (94% Efficient)
FeaturesHP iLO Management Engine
Package ContentsProLiant DL380p Gen8 E5-2690v2 2P 32GB-R P420i/2GB FBWC 750W RPS Server
High Voltage Server-to-PDU Power Cord
Shipping weight32.89 kg
Package size920 × 889 × 265 mm

Questions about this item

How much heat and power should I expect from the two Xeon E5-2690 v2 CPUs running continuously?

Each Xeon E5-2690 v2 has a 130 W thermal design power; the system includes two 750 W platinum power supplies rated at 94 % efficiency to handle the load.

Which drive caddies or backplane parts must I already have to populate the 2.5-inch bays?

The server ships with six SFF hard-drive blanks; you will need compatible 2.5-inch SAS or SATA drive carriers to install your own drives.

Can I keep using my existing DDR3 ECC RDIMMs alongside the installed 32 GB?

The 24 DIMM slots support DDR3-1866 registered ECC modules; you can add matching sticks up to the 384 GB maximum capacity.
