HPE DL360 Gen9 4LFF Xeon E5-2620 v3 384GB DDR4 rack server

HPE DL360 Gen9 4LFF server for dense compute

The HPE DL360 Gen9 4LFF is a 1U rack server built for workloads that need high memory capacity in a compact form factor. It ships with a single Intel Xeon E5-2620 v3 processor running at 2.4GHz and 384GB of DDR4 ECC registered memory. This configuration suits virtualization hosts, database nodes, or application tiers that benefit from large memory footprints. The chassis supports up to two processors and 768GB maximum memory for future growth.

384GB DDR4 ECC registered memory installed

The decisive specification is the 384GB of DDR4 ECC registered memory already populated across the DIMM slots. This capacity determines how many virtual machines, containers, or in-memory datasets the server can handle without swapping. The system uses DDR4 technology exclusively; earlier or later DDR generations are physically and electrically incompatible. Buyers who need more than 768GB total capacity or a different memory generation must choose another platform.

P440 SAS controller and 10GbE networking included

The bundled HPE Smart Array P440 SAS controller provides hardware RAID for up to four 3.5-inch SATA drives, enabling redundancy or performance profiles without a separate card. Dual 500W flex-slot power supplies deliver redundant power out of the box. Integrated HPE iLO Advanced remote management allows firmware updates, power control, and console access over the network. The installed dual-port 10GbE and dual-port 1GbE adapter eliminates the need for additional networking cards in most rack deployments.
