Silver rack-mount server chassis with twelve front drive bays

HPE

HPE DL380 Gen9 12LFF 1x Xeon E5-2699v4 384GB DDR4 rack server

SKU CH-WMFZ-G109T

12-bay 3.5-inch rack server with a 22-core Xeon E5-2699v4 at 2.2 GHz and 384 GB DDR4 ECC memory

  • TypeRack
  • CPU TypeIntel Xeon
  • CPU Speed2.2GHz
  • # of Processors Installed1
  • MAX Processors2
  • Installed Memory Size384GB
  • 12 LFF drive bays fit 3.5 inch SATA storage
  • 22-core Xeon E5-2699 v4 runs at 2.2 GHz with 55 MB cache
  • 384 GB DDR4 ECC registered memory supports heavy workloads
  • P440ar SAS controller plus expander manages up to 12 drives
  • Dual 800 W hot-plug power supplies with Intel 10 GbE and 1 GbE networking

HPE DL380 Gen9 12-Bay Server

The HPE ProLiant DL380 Gen9 is a 2U rack server built for dense storage workloads. It ships with a single Intel Xeon E5-2699 v4 processor running at 2.2 GHz with 22 cores and 55 MB cache. The chassis supports up to twelve 3.5-inch SATA or SAS drives via a Smart Array P440ar controller with expander. 384 GB of DDR4 ECC registered memory is installed across the available DIMM slots.

Suited For And Not Suited For

This configuration suits organisations that need high core counts and large memory capacity for virtualisation, database or analytics tasks. The twelve-bay LFF chassis provides substantial raw capacity for backup repositories or media archives. Buyers who require a second processor for maximum throughput or who need 2.5-inch drive bays for higher spindle counts should look at alternative chassis options.

Deciding Specification 384GB DDR4

The installed 384 GB of DDR4 ECC registered memory is the critical figure for workload sizing. It determines how many virtual machines, database buffers or analytics datasets can reside in RAM simultaneously. The system board supports a maximum of 3 TB when fully populated across two processors, so this single-socket build leaves significant headroom for future expansion.

Highlights

  • 12 LFF drive bays fit 3.5 inch SATA storage
  • 22-core Xeon E5-2699 v4 runs at 2.2 GHz with 55 MB cache
  • 384 GB DDR4 ECC registered memory supports heavy workloads
  • P440ar SAS controller plus expander manages up to 12 drives
  • Dual 800 W hot-plug power supplies with Intel 10 GbE and 1 GbE networking

Specifications

BrandHP
SeriesProLiant
ModelRack Mount
TypeRack
CPU TypeIntel Xeon
CPU Speed2.2GHz
# of Processors Installed1
MAX Processors2
Installed Memory Size384GB
Memory TypeDDR4
Max Memory Capacity3TB
Hard Drive (Installed)8,00
Storage ControllerHP Smart Array P440ar And Sas Expander
HDD InterfaceSATA
GPU TypeIntegrated Graphics
Remote ManagementHPE iLO Advanced
Dimensions36 x 24 x 10 in
Weight40

Questions about this item

Should I pick the 12-bay 3.5-inch chassis or a smaller drive cage for this DL380 Gen9?

The 12-bay 3.5-inch chassis gives you the full complement of large-form-factor slots; choose it when you need maximum capacity with SATA or SAS hard drives, and select a smaller cage only if your workload fits in fewer bays.

What does the Xeon E5-2699 v4's 22 cores at 2.2 GHz deliver in this server?

Twenty-two cores running at 2.2 GHz provide 44 threads for heavily threaded workloads such as virtualisation, databases or render farms, with 55 MB cache reducing latency on large data sets.

How does the P440ar SAS controller with expander limit drive performance?

The P440ar connects all 12 bays through a 12 Gb/s SAS expander, so each SATA or SAS drive shares that aggregate bandwidth; sequential throughput per drive is capped by the SATA 6 Gb/s link, while random IOPS scale with the number of active spindles.
