Silver 2U rack server with twelve 3.5 inch drive bays visible on the front

HPE

HPE DL380 Gen9 12LFF 2x Xeon E5-2699v4 32GB DDR4 rack server

SKU CH-1GCC-C74G7

A 12-bay 3.5-inch rack server with dual 22-core Xeon processors at 2.2 GHz and 32 GB DDR4 ECC memory, ready for custom storage

  • TypeRack
  • CPU TypeIntel Xeon
  • CPU Speed2.2GHz
  • # of Processors Installed2
  • MAX Processors2
  • Installed Memory Size32GB
  • Dual 22-core Xeon E5-2699 v4 processors deliver 44 threads for heavy compute workloads
  • 12 LFF 3.5" drive bays provide high-capacity local storage flexibility
  • 32 GB DDR4 ECC registered memory supports error-corrected performance out of the box
  • Integrated HPE iLO Advanced remote management enables lights-out server administration
  • Dual 800 W hot-plug power supplies with P440ar SAS controller ensure resilient power and storage connectivity

Dual Xeon 22-core rack server

The HPE DL380 Gen9 12LFF chassis arrives new with two Xeon E5-2699v4 processors running at 2.2GHz, delivering 44 cores and 55MB cache per CPU. 32GB of DDR4 ECC registered memory is installed across two 16GB modules. The system includes a P440ar SAS controller with expander, dual 800W hot-plug power supplies, and an Intel network card providing two 10GbE and two 1GbE ports. Remote management is handled by HPE iLO Advanced.

Suits dense 3.5-inch storage builds.

This 12-bay large-form-factor chassis targets organisations that require maximum 3.5-inch drive capacity in a 2U rack footprint. The dual-processor configuration supports memory expansion up to 3TB for virtualisation or database workloads. Buyers who need 2.5-inch small-form-factor bays, higher factory-installed memory, or pre-populated storage drives should evaluate alternative configurations.

12-bay 3.5-inch chassis dictates drive choice

The defining specification is the 12LFF chassis, which accepts only 3.5-inch SATA or SAS drives. All twelve bays are empty, so the buyer must source compatible large-form-factor drives separately. The installed P440ar controller manages these drives through the SAS expander, but the physical bay count and form factor are fixed by the chassis design.

Highlights

  • Dual 22-core Xeon E5-2699 v4 processors deliver 44 threads for heavy compute workloads
  • 12 LFF 3.5" drive bays provide high-capacity local storage flexibility
  • 32 GB DDR4 ECC registered memory supports error-corrected performance out of the box
  • Integrated HPE iLO Advanced remote management enables lights-out server administration
  • Dual 800 W hot-plug power supplies with P440ar SAS controller ensure resilient power and storage connectivity

Specifications

BrandHP
SeriesProLiant
ModelRack Mount
TypeRack
CPU TypeIntel Xeon
CPU Speed2.2GHz
# of Processors Installed2
MAX Processors2
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity3TB
Hard Drive (Installed)20,00
Storage ControllerHP Smart Array P440ar And Sas Expander
HDD InterfaceSATA
GPU TypeIntegrated Graphics
Remote ManagementHPE iLO Advanced
Dimensions36 x 24 x 10 in
Weight40

Questions about this item

What does the 2.2 GHz base clock on the two Xeon E5-2699v4 processors deliver in this server?

The dual 22-core CPUs provide 44 threads at 2.2 GHz, giving strong multi-threaded throughput for virtualisation and database workloads in a 2U chassis.

How does the P440ar SAS controller with expander limit drive performance in the 12-bay LFF cage?

The controller connects all 12 bays through a single SAS expander, so aggregate throughput is shared across the installed SATA drives.

What physical space and mounting hardware does the 36 by 24 by 10 inch 2U rackmount need?

The unit occupies 2U of rack height and 24 inches of depth; a compatible rail kit is available on request for square-hole or threaded racks.
