HPE
HPE DL380 Gen9 12LFF Xeon E5-2620 v3 2.4GHz 128GB DDR4 rack server
A 12-bay 3.5-inch rack server with one Xeon E5-2620 v3 at 2.4GHz and 128GB DDR4 memory
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.4GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size128GB
- 12 LFF bays support 3.5" drives for high capacity
- 128 GB DDR4 ECC memory handles demanding workloads
- Xeon E5-2620 v3 2.4 GHz 6-core CPU delivers solid compute
- P440ar SAS controller with expander manages RAID arrays
- Dual 800 W hot-plug supplies keep power redundant
HPE DL380 Gen9 12-bay rack server
The HPE DL380 Gen9 is a 2U rack-mount server with twelve 3.5-inch drive bays. It ships with one Intel Xeon E5-2620 v3 processor running at 2.4 GHz and 128 GB of DDR4 ECC registered memory. The system includes a Smart Array P440ar SAS controller with expander and dual 800 W hot-plug power supplies. Remote management is provided through HPE iLO Advanced.
Suited for storage-heavy workloads.
This configuration suits buyers who need dense 3.5-inch storage capacity in a standard rack footprint and want a second processor socket available for future expansion. The integrated graphics and single CPU make it a poor fit for workloads that require GPU acceleration or high single-thread performance. Buyers who want more than twelve drive bays or a smaller chassis should look at something else.
Twelve 3.5-inch drive bays
The chassis supports up to twelve 3.5-inch SATA drives managed by the installed P440ar controller and SAS expander. No drives are included, so the buyer must supply compatible SATA HDDs or SSDs. This bay count and controller combination is the key specification that determines whether the server matches the intended storage topology.
Highlights
- 12 LFF bays support 3.5" drives for high capacity
- 128 GB DDR4 ECC memory handles demanding workloads
- Xeon E5-2620 v3 2.4 GHz 6-core CPU delivers solid compute
- P440ar SAS controller with expander manages RAID arrays
- Dual 800 W hot-plug supplies keep power redundant
Specifications
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.4GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 128GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 3TB |
| Hard Drive (Installed) | 2,00 |
| Storage Controller | HP Smart Array P440ar And Sas Expander |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
How many additional DDR4 memory modules can I add to reach the 3TB maximum capacity?
The server currently has 128GB DDR4 installed and supports up to 3TB total, leaving room for additional DDR4 modules across the remaining DIMM slots.
Which component will hit its limit first during continuous heavy workloads on the Xeon E5-2620 v3?
The single Xeon E5-2620 v3 processor with six cores and 15MB cache will reach its compute ceiling before the 128GB DDR4 memory or dual 800W power supplies become constrained.
How loud and hot does the 12LFF chassis get when running 24/7 with both 800W power supplies active?
Dual 800W Flex Slot hot-plug power supplies and integrated cooling fans maintain stable temperatures; acoustic output is typical for a 2U rack server under sustained load.
