Silver 2U rack server front with eight 2.5 inch drive bays

HPE

HPE DL560 Gen9 8SFF rack server 4x Xeon E5-4650 v4 128GB DDR4

SKU CH-FWFC-KAZZ0

Rack server with four 2.2 GHz Xeon processors and 128 GB DDR4 memory, supporting up to eight 2.5-inch drives

  • TypeRack
  • CPU TypeIntel Xeon
  • CPU Speed2.2GHz
  • # of Processors Installed4
  • MAX Processors4
  • Installed Memory Size128GB
  • Four 14-core Xeon processors deliver 56 threads at 2.2 GHz
  • 128 GB DDR4 ECC memory supports demanding virtualization workloads
  • Eight 2.5-inch drive bays ready for SATA storage expansion
  • Dual 800 W hot-plug power supplies provide redundant power
  • HPE iLO Advanced enables remote firmware updates and monitoring

Four-processor Xeon server for dense compute

The HPE ProLiant DL560 Gen9 packs four Intel Xeon E5-4650 v4 processors, each running at 2.2GHz with 14 cores and 35MB cache, into a 2U rack chassis that supports up to eight 2.5-inch drive bays. It ships with 128GB of DDR4 ECC registered memory and can scale to 3TB, making it suited for virtualization hosts, database clusters or high-throughput batch workloads that need many threads in a single rack unit.

Dual 800W hot-plug supplies and integrated iLO

Two 800W Flex Slot hot-plug power supplies provide redundancy while the integrated HPE iLO Advanced remote-management controller lets administrators monitor thermals, power draw and system health without being on site. The 10-inch chassis depth keeps airflow paths short, and the latest firmware is pre-loaded so the platform runs at validated thermal and acoustic targets from first boot.

No drives or RAID card installed.

The unit arrives without storage drives or a dedicated RAID controller, so you choose the exact SATA SSD or HDD mix and the RAID level that matches your capacity and resilience needs. An Intel I350/X540 quad-port network card delivering two 10GbE and two 1GbE links is already fitted, and a rail kit can be added on request to complete the rack installation.

Highlights

  • Four 14-core Xeon processors deliver 56 threads at 2.2 GHz
  • 128 GB DDR4 ECC memory supports demanding virtualization workloads
  • Eight 2.5-inch drive bays ready for SATA storage expansion
  • Dual 800 W hot-plug power supplies provide redundant power
  • HPE iLO Advanced enables remote firmware updates and monitoring

Specifications

BrandHP
SeriesProLiant
ModelRack Mount
TypeRack
CPU TypeIntel Xeon
CPU Speed2.2GHz
# of Processors Installed4
MAX Processors4
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity3TB
Hard Drive (Installed)3.840,00
Storage ControllerIntegrated Controller
HDD InterfaceSATA
GPU TypeIntegrated Graphics
Remote ManagementHPE iLO Advanced
Dimensions36 x 24 x 10 in
Weight40

Questions about this item

How do I install the 2.5" drives into the 8SFF chassis and what step is often missed?

Slide each drive into a bay until the latch clicks, then verify the LED turns green; the step often missed is seating the latch fully so the backplane connector engages.

Which components will need replacement first under continuous operation?

The two 800W hot-plug power supplies and system fans are the primary field-replaceable units that wear over time.

What thermal limit appears first when all 4 Xeon E5-4650 v4 CPUs run at 2.2GHz sustained load?

The chassis airflow limit is reached before CPU throttling, so adequate front-to-rear cooling must be maintained.
