Silver 1U rack server with front drive bays and ventilation grilles

HPE

HPE P83279-005 ProLiant DL20 Gen11 Xeon 6325P 3.5GHz 4-core 16GB 2x1TB SATA 1U rack server

SKU CH-QGQE-A4VEM MPN P83279-005

1U rack server with a 3.5 GHz quad-core Xeon 6, 16 GB DDR5 and two 1 TB SATA drives

  • WorkloadGeneral Purpose Server
  • TypeRack
  • Rack Height1U
  • Hot-swap Fans3 x High Performance Fans
  • CPU TypeIntel Xeon 6
  • CPU Speed6325P (3.50 GHz)
  • Quad-core Xeon 6325P at 3.50 GHz delivers responsive compute
  • 16 GB DDR5 4800 MT/s memory supports smooth multitasking
  • 2 TB total storage on two 1 TB SATA business-critical drives
  • Four-port 1 Gb embedded adapter provides flexible network connectivity
  • Compact 1U rack form factor fits dense data-centre deployments

HPE ProLiant DL20 Gen11 1U rack server

This 1U rack server is built for general-purpose workloads and ships with an Intel Xeon 6 6325P processor running at 3.50 GHz across four cores. It includes 16 GB of DDR5 UDIMM memory at 4800 MT/s and two 1 TB SATA hard drives spinning at 7.2K RPM. The system fits a standard 19-inch rack and uses a single 290 W power supply.

Installation and common issues

The server arrives assembled and ready to rack-mount using standard square-hole or threaded rails. Three hot-swap fans are pre-installed for front-to-rear airflow. The embedded Intel VROC SATA controller manages the two included drives without an extra RAID card. Builders should verify that the rack depth accommodates the 27.32 inch chassis and that power distribution units can supply the 290 W unit.

Pre-order checks

Confirm that your rack provides at least 1U of vertical space and sufficient depth for the 27.32 inch length. The system includes a four-port 1 GbE network adapter, so plan switch ports accordingly. Only two large-form-factor drive bays are available and both are occupied by the factory-installed drives. Memory expansion beyond the single 16 GB UDIMM will require compatible DDR5 modules.

Highlights

  • Quad-core Xeon 6325P at 3.50 GHz delivers responsive compute
  • 16 GB DDR5 4800 MT/s memory supports smooth multitasking
  • 2 TB total storage on two 1 TB SATA business-critical drives
  • Four-port 1 Gb embedded adapter provides flexible network connectivity
  • Compact 1U rack form factor fits dense data-centre deployments

Specifications

BrandHPE
SeriesProLiant DL20 Gen11
ModelP83279-005
WorkloadGeneral Purpose Server
TypeRack
Rack Height1U
Hot-swap Fans3 x High Performance Fans
CPU TypeIntel Xeon 6
CPU Speed6325P (3.50 GHz)
Number of CPU CoresQuad-Core Processor
Cache Memory12 MB L3 Cache
# of Processors Installed1
Installed Memory Size16 GB (1x16 GB UDIMM, 4800 MT/s)
Memory TypeHPE DDR5 Standard Memory
Hard Drive (Installed)2 x HPE 1TB SATA 6G Business Critical 7.2K LFF LP
Storage ControllerEmbedded Intel VROC SATA (formerly known as Intel RSTe)
HDD InterfaceSATA
Ethernet ControllerHPE embedded 1GB 4-port BCM5719 Network Adapter
Expansion BaysTwo maximum
Power Characteristics1 x HPE ProLiant DL20 Gen10 Plus 290W FIO Power Supply Kit
Dimensions10.55" x 27.32" x 23.07"
Weight25.397 lbs.
Shipping weight18.14 kg
Package size508 × 508 × 152 mm

Questions about this item

How can I verify the Intel Xeon 6325P 3.50 GHz 4-core processor and 16 GB DDR5 4800 MT/s memory are recognised after first boot?

Enter the system BIOS or iLO interface on start-up; both will display the installed Xeon 6325P at 3.50 GHz with 4 cores and the single 16 GB UDIMM running at 4800 MT/s.

Which components ship inside the 1U chassis and what must I source separately?

The box contains the DL20 Gen11 chassis, one Xeon 6325P processor, one 16 GB DDR5 UDIMM, two 1 TB SATA 7.2K LFF drives, three hot-swap fans and one 290 W power supply; rails, additional drives, memory modules or a redundant PSU are not included.

Should I choose the 2 x 1 TB SATA configuration or add more drives to the two available LFF bays?

The server arrives with both LFF bays filled by the 1 TB SATA drives; if you need more capacity you must replace one or both drives with larger LFF SATA models because no empty bays remain.
