1U silver rack server with front drive bays and power supply visible

HPE

HPE ProLiant DL20 Gen11 P83278-005 Xeon 6315P 2.8GHz 4-Core 16GB DDR5 2x1TB SATA rack server

SKU CH-ZJSQ-40NDS MPN P83278-005

A 1U rack server with a quad-core Xeon 6315P at 2.8 GHz, 16 GB DDR5, and two 1 TB SATA drives

  • WorkloadGeneral Purpose Server
  • TypeRack
  • Rack Height1U
  • Hot-swap Fans3 x High Performance Fans
  • CPU TypeIntel Xeon 6
  • CPU Speed6315P (2.80 GHz)
  • Quad-core Xeon 6315P at 2.8 GHz handles general-purpose workloads
  • 16 GB DDR5 UDIMM at 4800 MT/s provides high-speed memory
  • Two 1 TB SATA 7.2K LFF drives deliver 2 TB storage
  • Embedded Intel VROC SATA controller manages drives efficiently
  • Four-port 1 GbE BCM5719 adapter connects to multiple networks

HPE ProLiant DL20 Gen11 1U rack server

This 1U rack server is built for general-purpose workloads in small-to-medium business environments. It ships with a single Intel Xeon 6 6315P processor running at 2.80 GHz with four cores and 12 MB L3 cache. The platform supports a maximum of one processor, so CPU upgrades are not an option. It is designed for standard rack installations where space efficiency matters.

Bundled storage and power supply details

Two 1 TB SATA 6G business-critical 7.2K LFF hard drives are pre-installed and managed by the embedded Intel VROC SATA controller. A single 290 W FIO power supply kit provides power, with no redundant PSU included. The system also includes an embedded 1 Gb 4-port BCM5719 network adapter and three high-performance hot-swap fans for cooling. These components define the baseline storage, networking and power capacity out of the box.

Memory slots and expansion bay limits

The server arrives with one 16 GB DDR5 UDIMM at 4800 MT/s installed in a single slot. Additional memory must match the DDR5 UDIMM specification to be compatible. Only two expansion bays are available in total, and both are occupied by the factory-installed drives. Buyers needing more internal storage or add-in cards must plan around this constraint.

Highlights

  • Quad-core Xeon 6315P at 2.8 GHz handles general-purpose workloads
  • 16 GB DDR5 UDIMM at 4800 MT/s provides high-speed memory
  • Two 1 TB SATA 7.2K LFF drives deliver 2 TB storage
  • Embedded Intel VROC SATA controller manages drives efficiently
  • Four-port 1 GbE BCM5719 adapter connects to multiple networks

Specifications

BrandHPE
SeriesProLiant DL20 Gen11
ModelP83278-005
WorkloadGeneral Purpose Server
TypeRack
Rack Height1U
Hot-swap Fans3 x High Performance Fans
CPU TypeIntel Xeon 6
CPU Speed6315P (2.80 GHz)
Number of CPU CoresQuad-Core Processor
Cache Memory12 MB L3 Cache
# of Processors Installed1
MAX Processors1
Installed Memory Size16 GB (1x16 GB UDIMM, 4800 MT/s)
Memory TypeHPE DDR5 Standard Memory
Hard Drive (Installed)2 x HPE 1TB SATA 6G Business Critical 7.2K LFF RW
Storage ControllerEmbedded Intel VROC SATA (formerly known as Intel RSTe)
HDD InterfaceSATA
Ethernet ControllerHPE embedded 1GB 4-port BCM5719 Network Adapter
Expansion BaysTwo maximum
Power Characteristics1 x HPE ProLiant DL20 Gen10 Plus 290W FIO Power Supply Kit
Dimensions10.55" x 27.32" x 23.07"
Weight24.714 lbs.
Shipping weight18.14 kg
Package size508 × 508 × 152 mm

Questions about this item

How often do the three high-performance fans need to be replaced?

The three high-performance fans are hot-swap modules; replacement interval depends on environmental conditions and workload but the chassis supports tool-less removal without downtime.

What limits sustained throughput on the 1 TB SATA drives?

The 7.2 K RPM SATA drives and the embedded Intel VROC SATA controller cap sustained sequential throughput at the SATA 6 Gb/s interface ceiling.

How much power does the 290 W supply draw under continuous load?

The single 290 W FIO power supply delivers up to 290 W to the system; actual draw varies with CPU utilisation, memory activity and drive I/O.
