Silver 1U rack server front with four drive bays and dual power supplies

HPE

HPE ProLiant DL20 Gen11 P86810-005 Xeon 6333P 3.1GHz 6-Core 32GB DDR5 2x960GB SATA SSD 2x500W Rack Server

SKU CH-9T93-YRYK7 MPN P86810-005

A 1U rack server with a 6-core 3.10 GHz Xeon, 32 GB DDR5, dual 960 GB SATA SSDs and redundant 500 W power supplies

  • WorkloadGeneral Purpose Server
  • TypeRack
  • Rack Height1U
  • Hot-swap Fans3 x High Performance Fans
  • CPU TypeIntel Xeon 6
  • CPU Speed6333P (3.10 GHz)
  • Six-core Xeon 6333P at 3.10 GHz handles demanding workloads
  • 32 GB DDR5 UDIMM at 4800 MT/s speeds memory-intensive tasks
  • Dual 960 GB SATA SSDs deliver fast mixed-use storage
  • MR408i-o controller with 4 GB cache accelerates RAID performance
  • Redundant 500 W hot-plug power supplies ensure continuous uptime

1U rack server for general-purpose workloads

The HPE ProLiant DL20 Gen11 fits a single Intel Xeon 6333P six-core processor running at 3.1 GHz with 18 MB L3 cache. It ships with 32 GB of DDR5 memory in a single 4800 MT/s UDIMM. Two 960 GB SATA mixed-use SSDs are pre-installed behind the HPE MR408i-o storage controller with 4 GB cache. Dual 500 W hot-plug power supplies and an embedded four-port 1 GbE adapter complete the base configuration.

Hot-swap fans and front-access drive bays

Three high-performance fans are hot-swappable, allowing airflow maintenance without downtime. The 1U chassis provides four small-form-factor drive bays, two of which are populated with the included SSDs. The OCP SPDM storage controller occupies an internal slot, leaving the front panel free for additional SATA drives. Redundant power supplies are also hot-pluggable, so a failed unit can be replaced while the server remains online.

Verify rack depth and memory expansion headroom

The 1U form factor demands a rack with sufficient depth for cable management and airflow clearance. Only one memory slot is populated, so further DDR5 UDIMM upgrades are possible within the platform limits. The single-processor design means no second CPU can be added later. Buyers needing 10 GbE or additional OCP cards should confirm slot availability before ordering.

Highlights

  • Six-core Xeon 6333P at 3.10 GHz handles demanding workloads
  • 32 GB DDR5 UDIMM at 4800 MT/s speeds memory-intensive tasks
  • Dual 960 GB SATA SSDs deliver fast mixed-use storage
  • MR408i-o controller with 4 GB cache accelerates RAID performance
  • Redundant 500 W hot-plug power supplies ensure continuous uptime

Specifications

BrandHPE
SeriesProLiant DL20 Gen11
ModelP86810-005
WorkloadGeneral Purpose Server
TypeRack
Rack Height1U
Hot-swap Fans3 x High Performance Fans
CPU TypeIntel Xeon 6
CPU Speed6333P (3.10 GHz)
Number of CPU Cores6-Core Processor
Cache Memory18 MB L3
# of Processors Installed1
Installed Memory Size32GB
Memory TypeHPE DDR5 Standard Memory
Memory Features1 x 32GB UDIMM, 4800 MT/s
Storage ControllerHPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
SSD (Installed)2 x HPE 960GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
Ethernet ControllerHPE embedded 1GB 4-port BCM5719 Network Adapter
Power Characteristics2 x HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
Shipping weight18.14 kg
Package size483 × 457 × 127 mm

Questions about this item

What does the embedded 1 GbE 4-port BCM5719 adapter cap at in practice?

The four-port BCM5719 adapter is limited to 1 Gbps per port, so total throughput cannot exceed 1 Gbps on any single connection.

What rack depth and airflow clearance does the 1U DL20 Gen11 need?

The server is a 1U rack unit with three high-performance hot-swap fans; it requires a standard 1U slot and front-to-rear airflow clearance in a four-post rack.

How is the MR408i-o storage controller installed, and what step is often missed?

The MR408i-o controller occupies an OCP 3.0 slot; the step often missed is enabling the controller in the system BIOS before creating RAID volumes.
