Silver 1U rack server front with drive bays and power button

HPE

HPE ProLiant DL320 G11 1U Rack Server P69302-005 Xeon Gold 5416S 16C 2.00GHz 64GB DDR5

SKU CH-86M6-ZJBX6 MPN P69302-005

1U rack server with a 16-core Xeon Gold 5416S at 2.00GHz and 64GB DDR5 memory

  • WorkloadGeneral Purpose Server
  • TypeRack
  • Rack Height1U
  • Hot-swap Fans7x High Performance Fans
  • SecurityUEFI Secure Boot and Secure Start support. Intel Software Gu
  • CPU TypeIntel Xeon Gold

Installed Memory Size 64GB

CPU Model Xeon Gold 5416S

Option None Storage

  • 16-core Xeon Gold 5416S handles heavy workloads at 2.00 GHz
  • 64 GB DDR5 Smart Memory at 4800 MT/s accelerates data-intensive tasks
  • 30 MB L3 cache reduces latency for faster retrieval
  • 7 high-performance hot-swap fans maintain thermal stability under load
  • HPE NS204i-u NVMe boot device enables rapid system startup

General-purpose 1U rack server

The HPE ProLiant DL320 G11 is a 1U rackmount server built for general-purpose workloads. It ships with a single Intel Xeon Gold 5416S 16-core processor running at 2.00 GHz and 64 GB of HPE DDR5 Smart Memory configured as two 32 GB modules at 4800 MT/s. The platform supports a maximum of one processor and up to 2.04 TB of total memory. Security features include UEFI Secure Boot, Secure Start, Intel SGX and an Immutable Silicon Root of Trust.

7 high-performance fans

Seven hot-swap high-performance fans provide active cooling for the 150 W TDP processor and other components in the 1U chassis. Redundant power is delivered by two HPE 800 W Flex Slot Platinum hot-plug low-halogen power supply kits. The power supplies support hot-plug replacement without downtime. Acoustic output will vary with workload and fan speed settings.

8 SFF bays, PCIe Gen5 slots and OCP 3.0

Storage connectivity uses an HPE NS204i-u Gen11 NVMe hot-plug boot optimised storage device and the chassis supports eight SFF drive bays. Expansion includes one PCIe Gen5 slot and one OCP 3.0 PCIe Gen5 slot, with support for up to two double-wide or four single-wide PCIe accelerators. Networking is handled by a Broadcom BCM5720 1 Gb 2-port BASE-T adapter. Four USB ports and two RJ-45 ports provide additional I/O.

Highlights

  • 16-core Xeon Gold 5416S handles heavy workloads at 2.00 GHz
  • 64 GB DDR5 Smart Memory at 4800 MT/s accelerates data-intensive tasks
  • 30 MB L3 cache reduces latency for faster retrieval
  • 7 high-performance hot-swap fans maintain thermal stability under load
  • HPE NS204i-u NVMe boot device enables rapid system startup

Specifications

BrandHPE
SeriesProLiant DL320 G11
ModelP69302-005
WorkloadGeneral Purpose Server
TypeRack
Rack Height1U
Hot-swap Fans7x High Performance Fans
SecurityUEFI Secure Boot and Secure Start support.
Intel Software Guard Extensions (SGX) support.
Immutable Silicon Root of Trust.
CPU TypeIntel Xeon Gold
CPU Speed5416S (2.00GHz)
Number of CPU Cores16-Core Processor
Cache Memory30 MB L3 Cache
CPU FeaturesTDP 150W
# of Processors Installed1
MAX Processors1
Installed Memory Size64GB (2x32GB, 4800 MT/s)
Memory TypeHPE DDR5 Smart Memory
Storage ControllerHPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device
GPU TypeSupports up to 2 double wide or 4 single wide PCIe Accelerators (GPU),
Ethernet ControllerBroadcom BCM5720 Ethernet 1Gb 2-port BASE-T Adapter
Expansion SlotsOne PCIe Gen5 & One OCP 3.0 PCIe Gen5
Expansion Bays8 SFF supported
Power Characteristics2 x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
Shipping weight24.99 kg
Package size918 × 600 × 270 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the HPE NS204i-u Gen11 NVMe boot device in the DL320 G11?

Insert the boot device into the dedicated internal M.2 slot on the system board; the step often missed is engaging the retention latch until it clicks.

What maintenance will the 800W Flex Slot Platinum power supplies need over time?

The hot-plug supplies are rated for continuous operation; plan to clean the 7 high-performance fan rotors and replace any supply that reports a fault via iLO.

Which limit appears first when the Xeon Gold 5416S runs sustained workloads in this 1U chassis?

The 150 W TDP combined with 1U airflow means the 7 high-performance fans ramp to maximum speed before the CPU hits thermal throttle.
