Silver 1U rack server with front drive bays and dual power supplies

HPE

HPE ProLiant DL320 Gen12 P87790-005 Xeon 6505P 2.2GHz 12-Core 64GB DDR5 2x480GB SATA SSD 1U Rack Server

SKU CH-45F7-8C0TM MPN P87790-005

A 1U rack server with a 12-core Xeon 6505P at 2.2 GHz, 64 GB DDR5, and dual 480 GB SATA SSDs

  • WorkloadGeneral Purpose Server
  • TypeRack
  • Rack Height1U
  • Hot-swap Fans7 x High Performance Fans
  • SecurityUEFI Secure Boot and Secure Start support Intel Software Gua
  • CPU TypeIntel Xeon 6
  • Intel Xeon 6 12-core processor at 2.2 GHz delivers responsive compute performance
  • 64 GB DDR5 Smart Memory at 6400 MT/s enables fast data access for demanding workloads
  • Two 480 GB SATA SSDs provide immediate storage capacity for operating system and applications
  • Four-port 1 GbE Broadcom BCM5719 OCP3 adapter connects the server to existing network infrastructure
  • Dual 1000 W Titanium hot-plug power supplies maintain uptime through redundant power delivery

1U Rack Server for General Purpose Workloads

This HPE ProLiant DL320 Gen12 is a 1U rack server built for general purpose workloads. It ships with a single Intel Xeon 6 6505P 12-core processor running at 2.20 GHz and 64 GB of HPE DDR5 Smart Memory at 6400 MT/s. Two 480 GB SATA SSDs are installed on an MR408i-o storage controller. Dual 1000 W Titanium hot-plug power supplies provide redundancy.

PCIe Gen5 and OCP 3.0 Expansion Limits

The chassis offers up to six PCIe Gen5 slots and two OCP 3.0 slots with a Rich IO Processor. Networking is handled by a Broadcom BCM5719 1 GbE 4-port BASE-T OCP3 adapter. Storage expansion relies on the MR408i-o Gen11 controller using x8 lanes with 4 GB cache. The 1U height and seven high-performance hot-swap fans constrain the thermal envelope for add-in cards.

Verify Rack Depth and Power Infrastructure

Before ordering, confirm your rack provides sufficient depth for a 1U server with dual hot-plug power supplies. Ensure the facility can deliver the required power connections for two 1000 W units. Check that your network infrastructure supports 1 GbE connectivity across four ports. The single-socket design means CPU upgrades are limited to one processor.

Highlights

  • Intel Xeon 6 12-core processor at 2.2 GHz delivers responsive compute performance
  • 64 GB DDR5 Smart Memory at 6400 MT/s enables fast data access for demanding workloads
  • Two 480 GB SATA SSDs provide immediate storage capacity for operating system and applications
  • Four-port 1 GbE Broadcom BCM5719 OCP3 adapter connects the server to existing network infrastructure
  • Dual 1000 W Titanium hot-plug power supplies maintain uptime through redundant power delivery

Specifications

BrandHPE
SeriesProLiant DL320 G12
ModelP87790-005
WorkloadGeneral Purpose Server
TypeRack
Rack Height1U
Hot-swap Fans7 x High Performance Fans
SecurityUEFI Secure Boot and Secure Start support
Intel Software Guard Extensions (SGX) support
Intel Trust Domain Extensions (Intel TDX)
Immutable Silicon Root of Trust
TPM (Trusted Platform Module) 2.0 support
CPU TypeIntel Xeon 6
CPU Speed6505P (2.20 GHz)
Number of CPU Cores12-Core Processor
Cache Memory48 MB L3
CPU Features150W TDP
# of Processors Installed1
Installed Memory Size64GB
Memory TypeHPE DDR5 Smart Memory
Memory Features64 GB (1x64 GB, 6400 MT/s)
Storage ControllerHPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
SSD (Installed)2 x 480GB SATA SSD
Ethernet ControllerBroadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
Expansion SlotsUp to 6 PCIe Gen5, and 2 OCP 3.0 with Rich IO Processor
Power Characteristics2 x HPE 1000W M-CRPS Titanium Hot Plug Power Supply Kit
Shipping weight18.14 kg
Package size762 × 508 × 254 mm

Questions about this item

Should I pick the single 6505P processor or add a second CPU for this workload?

This unit ships with one Intel Xeon 6 6505P 12-core processor at 2.20 GHz and the board supports a single socket, so a second CPU cannot be added.

How does the 64 GB DDR5 module at 6400 MT/s perform once the server is running?

The installed 64 GB HPE DDR5 Smart Memory runs at 6400 MT/s in a single DIMM, leaving 15 slots free for future expansion up to the platform maximum.

What does the SATA interface mean for the two 480 GB SSDs in daily use?

The 480 GB drives connect through the HPE MR408i-o controller over SATA, providing reliable read-focused performance for boot, logs and light application data.
