HPE
HPE ProLiant DL325 Gen10+ 1U Rack Server EPYC 7702P 64C 2.0GHz 128GB DDR4 8x2.5
1U rack server with AMD EPYC 7702P 64-core 2.0 GHz processor, 128 GB DDR4 memory, eight 2.5-inch drive bays, P408i-a SR controller, dual 10/25 GbE and iLO 5 management
- TypeRack
- Rack Height1U
- Redundant Hot-swap PowerYes
- CPU TypeAMD EPYC
- CPU Speed2.00 GHz
- CPU SocketSP3
- AMD EPYC 7702P 64-core processor at 2.0 GHz base with 3.35 GHz turbo for high-throughput compute
- 128 GB DDR4 ECC memory installed across 16 slots supporting up to 2 TB capacity
- Eight 2.5-inch SFF hot-plug drive bays with HPE Smart Array P408i-a SR controller for SAS and SATA
- Dual 10/25 GbE network ports plus iLO 5 remote management for cloud-ready connectivity
- Redundant hot-swap 800 W power supplies in 1U rack form factor for enterprise uptime
Compact 1U rack server for virtualisation
The HPE ProLiant DL325 Gen10+ fits a single AMD EPYC 7702P with 64 cores at 2.0 GHz into a 1U chassis that holds eight 2.5-inch hot-plug bays. It ships with 128 GB DDR4 across 16 slots and an HPE Smart Array P408i-a SR controller. Dual 10/25 GbE ports and iLO 5 management are included with redundant 800 W power supplies.
Upgrade from smaller 1U or tower systems
This server replaces older single-socket platforms when core count and memory bandwidth become the bottleneck for consolidation. The jump is worth it when workloads need 64 threads and up to 2 TB DDR4 capacity without expanding beyond 1U of rack space. The P408i-a SR controller adds hardware RAID for SAS or SATA drives.
Suits virtualisation hosts and database nodes
Organisations running VMware, Hyper-V or Proxmox on a single dense node will benefit from the core density and 128 GB starting memory. Buyers who need more than one processor, GPU acceleration, or pre-installed storage should look at a different platform. The eight-bay limit also rules out large local capacity requirements.
Highlights
- AMD EPYC 7702P 64-core processor at 2.0 GHz base with 3.35 GHz turbo for high-throughput compute
- 128 GB DDR4 ECC memory installed across 16 slots supporting up to 2 TB capacity
- Eight 2.5-inch SFF hot-plug drive bays with HPE Smart Array P408i-a SR controller for SAS and SATA
- Dual 10/25 GbE network ports plus iLO 5 remote management for cloud-ready connectivity
- Redundant hot-swap 800 W power supplies in 1U rack form factor for enterprise uptime
Specifications
| Brand | HP |
|---|---|
| Series | Generation 10 Plus |
| Model | ProLiant DL325 |
| Type | Rack |
| Rack Height | 1U |
| Redundant Hot-swap Power | Yes |
| CPU Type | AMD EPYC |
| CPU Speed | 2.00 GHz |
| CPU Socket | SP3 |
| Number of CPU Cores | 64-Core Processor |
| CPU Features | EPYC 7702P |
| # of Processors Installed | 1 |
| MAX Processors | 1 |
| Chipset | SoC |
| Installed Memory Size | 128GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 2TB |
| Number of Memory Slots | 16 |
| Hard Drive (Installed) | None |
| Storage Controller | HPE Smart Array P408i-a SR |
| HDD Interface | SATA/SAS |
| SSD (Installed) | No |
| Raid Level | RAID 0/1/5/6/10/50/60 |
| GPU Type | Matrox G200 |
| Video Memory | 8 MB |
| Ethernet Controller | HPE Mellanox MCX562A Dual Port 10/25Gbps SFP28 OCP3 Network Adapter |
| LAN Ports | 2 x Ports |
| Expansion Slots | Up to 3 x PCIe 4.0 slots, 2 x16, 3 x16 with optional riser |
| Management Port | RJ 45 |
| Operating System | No |
| Features | 8 x 2.5" SATA/SAS Hot-Plug Drive Bays |
Questions about this item
What rack height and form factor does this 1U server require for mounting?
The unit is a 1U rack server, meaning it occupies a single rack unit of vertical space in a standard four-post rack; rails are included for secure mounting.
How is the HPE Smart Array P408i-a SR controller configured during initial setup, and what step is often missed?
The P408i-a SR is installed in a dedicated internal slot; the step often missed is creating the logical drive in the Smart Storage Administrator before installing the operating system.
Which memory specification must be matched when expanding the 128 GB DDR4 capacity later?
The server uses DDR4 ECC registered DIMMs across 16 slots with a maximum capacity of 2 TB; any added modules must be DDR4 ECC registered to be compatible.
