Silver 2U rack server with front drive bays and dual power supplies

HPE

HPE ProLiant DL380 Gen12 P89239-005 Xeon 6 6517P 16-core 64GB DDR5 480GB NVMe rack server

SKU CH-FFQF-8CM3B MPN P89239-005

2U rack server with 16-core Xeon 6517P, 64GB DDR5 and 480GB NVMe boot drive

  • WorkloadGeneral Purpose Server
  • TypeRack
  • Rack Height2U
  • Hot-swap Fans6 x High Performance Fan
  • SecurityHPE TPM 2.0 standard on motherboard
  • CPU TypeIntel Xeon 6
  • 16-core Xeon 6 6517P at 3.20 GHz for compute-intensive workloads
  • 64 GB DDR5 Smart Memory at 6400 MT/s for high-bandwidth applications
  • 480 GB NVMe boot device with hot-plug support for rapid OS deployment
  • 2U rack form factor with six hot-swap fans for dense datacentre cooling
  • Dual 1000 W Titanium hot-plug power supplies for efficient redundancy

General-purpose 2U rack server

This HPE ProLiant DL380 Gen12 system ships as a single-processor configuration built around an Intel Xeon 6 6517P running at 3.20 GHz with 16 cores and 72 MB of L3 cache. It includes 64 GB of DDR5 Smart Memory in two 32 GB modules operating at 6400 MT/s. A 480 GB NVMe boot device and a Broadcom BCM5719 four-port 1 GbE adapter are installed. The 2U chassis holds six high-performance hot-swap fans and two 1000 W Flex Slot Titanium power supplies.

Suited for standard workloads needing

The server fits organisations running virtualisation, databases or general-purpose applications that operate within one 190 W processor and 64 GB of memory. The MR408i-o storage controller and eight small-form-factor drive bays support local storage expansion. Buyers who require dual-processor compute density, higher-speed networking beyond 1 GbE, or larger boot capacity should evaluate other configurations.

Deciding specification — single Xeon 6 6517P

The installed processor defines the performance ceiling: 16 cores at 3.20 GHz with a 190 W TDP and no second CPU populated. If the target workload scales across more than 16 cores or demands a higher base frequency, this chassis will not meet the requirement without a processor upgrade. All other capabilities — memory slots, PCIe Gen5 lanes, OCP 3.0 slots and drive bays — are secondary to that CPU constraint.

Highlights

  • 16-core Xeon 6 6517P at 3.20 GHz for compute-intensive workloads
  • 64 GB DDR5 Smart Memory at 6400 MT/s for high-bandwidth applications
  • 480 GB NVMe boot device with hot-plug support for rapid OS deployment
  • 2U rack form factor with six hot-swap fans for dense datacentre cooling
  • Dual 1000 W Titanium hot-plug power supplies for efficient redundancy

Specifications

BrandHPE
SeriesProLiant DL380 G12
ModelP89239-005
WorkloadGeneral Purpose Server
TypeRack
Rack Height2U
Hot-swap Fans6 x High Performance Fan
SecurityHPE TPM 2.0 standard on motherboard
CPU TypeIntel Xeon 6
CPU Speed6517P (3.20 GHz)
Number of CPU Cores16-Core Processor
Cache Memory72 MB L3
CPU Features190W TDP
# of Processors Installed1
Installed Memory Size64GB
Memory TypeHPE DDR5 Smart Memory
Memory Features64 GB (2x32 GB, 6400 MT/s)
Storage ControllerHPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
SSD (Installed)HPE NS204i-u v2 480GB NVMe Hot Plug Boot Optimized Storage Device
Ethernet ControllerBroadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
Expansion SlotsUp to 8 PCIe Gen5, and 2 OCP 3.0 (front or rear)
Power Characteristics2 x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Shipping weight18.14 kg
Package size762 × 508 × 254 mm

Questions about this item

What rack depth and height does the 2U DL380 Gen12 chassis require?

The server occupies 2U of rack height and fits standard 19-inch racks; allow space for six high-performance hot-swap fans and front-to-rear airflow.

How is the OCP 3.0 adapter installed, and what step is often missed?

Insert the Broadcom BCM5719 1Gb 4-port BASE-T OCP3 adapter into an OCP 3.0 slot and seat the retention latch fully; the latch click is the step many skip.

When should the NS204i-u v2 480GB NVMe boot device be replaced?

Replace the hot-plug NVMe boot device when SMART health indicators show wear or after the rated write endurance is reached; it can be swapped without powering down.
