HPE ProLiant ML30 Gen11 P65096-001 Xeon E-2436 2.9GHz 6-core 16GB DDR5 8SFF rack server
Compact tower server with a six-core 2.9 GHz Xeon E-2436, 16 GB DDR5 memory and eight hot-plug small-form-factor drive bays
- WorkloadWorkstation
- TypeSmall Form Factor
- CPU TypeIntel Xeon E-2436 (6 core, 2.9 GHz, 12 MB Intel Smart Cache,
- CPU Speed2.90 GHz
- Number of CPU CoresQuad-Core Processor
- Cache Memory12 MB Intel Smart Cache
- Intel Xeon E-2436 6-core 2.9 GHz processor handles demanding workloads
- 16 GB DDR5 4800 MT/s memory delivers high-speed data access
- 8 SFF hot-plug drive bays provide flexible storage expansion
- PCIe Gen5 x16 slot enables high-bandwidth add-in cards
- Onboard M.2 NVMe SSD support accelerates boot and application performance
Compact workstation server
The HPE ProLiant ML30 Gen11 P65096-001 is a small form factor server built around a single Intel Xeon E-2436 processor running at 2.9 GHz with six cores. It ships with 16 GB of DDR5 memory operating at 4800 MT/s. This configuration targets workstation workloads that need reliable compute density in a compact chassis.
Expansion and power layout
The 8SFF hot-plug drive cage supports up to eight 2.5-inch drives while the single 500 W Flex Slot Platinum supply delivers power without redundancy. Four PCIe slots include one Gen5 x16 lane for high-bandwidth add-in cards and an onboard M.2 slot accepts NVMe SSDs. A dedicated iLO management port and optional serial kit provide out-of-band access for remote administration.
Sustained operation profile
The 65 W processor and non-hot-plug system fan are rated for continuous duty in typical office environments. Memory capacity can scale to 128 GB using validated 16 GB or 32 GB UDIMMs when workloads grow beyond the factory 16 GB. The platform supports Xeon E processors up to 8 cores and 95 W for future CPU upgrades within the same thermal envelope.
Highlights
- Intel Xeon E-2436 6-core 2.9 GHz processor handles demanding workloads
- 16 GB DDR5 4800 MT/s memory delivers high-speed data access
- 8 SFF hot-plug drive bays provide flexible storage expansion
- PCIe Gen5 x16 slot enables high-bandwidth add-in cards
- Onboard M.2 NVMe SSD support accelerates boot and application performance
Specifications
| Brand | HPE |
|---|---|
| Series | ProLiant |
| Model | ML30 Gen11 |
| Part Number | P65096-001 |
| Workload | Workstation |
| Type | Small Form Factor |
| CPU Type | Intel Xeon E-2436 (6 core, 2.9 GHz, 12 MB Intel Smart Cache, 65W) |
| CPU Speed | 2.90 GHz |
| Number of CPU Cores | Quad-Core Processor |
| Cache Memory | 12 MB Intel Smart Cache |
| CPU Features | 1x Non-hot plug non-redundant system fan |
| # of Processors Installed | 1 |
| Installed Memory Size | 16GB |
| Memory Type | DDR5 |
| Shipping weight | 4.54 kg |
| Package size | 584 × 495 × 330 mm |
Questions about this item
Does the 65 W Xeon E-2436 throttle under continuous load with the single non-hot-plug system fan?
The server ships with one non-hot-plug non-redundant fan; sustained heavy workloads on the 65 W processor will be limited by that single airflow path.
What noise and heat should I expect from the 500 W power supply running 24/7?
The 500 W Flex Slot Platinum supply and single system fan produce noticeable airflow noise and chassis warmth during all-day operation.
Which memory modules must I already have to expand beyond the installed 16 GB?
Expansion requires DDR5 UDIMMs rated at 4800 MT/s in 16 GB or 32 GB capacities, up to a total of 128 GB.
