HPE ProLiant ML30 Gen11 P65397-001 Xeon E-2434 16GB DDR5 8SFF 500W rack server
Tower server with a quad-core Xeon E-2434 at 3.4 GHz, 16 GB DDR5, eight hot-plug SFF bays and a 500 W power supply
- WorkloadWorkstation
- TypeTower
- Rack Height4U
- CPU TypeIntel Xeon E-2434 / 3.4 GHz (, up to 5 GHz, (Quad-Core)
- CPU Speed3.4 GHz
- Number of CPU CoresQuad-Core Processor
- Quad-core Xeon E-2434 at 3.4 GHz for responsive compute
- 16 GB DDR5 at 4800 MT/s for fast memory bandwidth
- 8 SFF hot-plug drive bays for flexible storage growth
- PCIe Gen5 x16 slot for high-speed expansion
- Dedicated iLO port simplifies remote management
ProLiant ML30 Gen11 Tower Server
The HPE ProLiant ML30 Gen11 is a 4U tower server built for workstation workloads. It ships with a single Intel Xeon E-2434 quad-core processor running at 3.4 GHz with up to 5 GHz turbo and 12 MB Smart Cache. Sixteen gigabytes of DDR5 memory are installed, and the chassis provides eight small form factor hot-plug drive bays. A single 500 W Flex Slot Platinum power supply is included.
Compatibility Checklist
Verify that your environment can accommodate a 4U tower form factor and that the 500 W power supply meets the total draw of all planned components. The system includes one non-hot-plug, non-redundant system fan, so airflow planning is essential. Confirm that any additional DDR5 UDIMMs you intend to add are 4800 MT/s HPE Standard Memory modules in 16 GB or 32 GB capacities. Ensure the operating system and applications support the installed Xeon E-2434 processor.
Build Integration
Four expansion slots are available, including one PCIe Gen5 x16 slot for high-bandwidth add-in cards. Onboard M.2 NVMe SSD support allows fast boot or cache drives without consuming a drive bay. The dedicated iLO management port enables remote administration separate from production network traffic. The eight hot-plug SFF bays free up internal space for storage expansion, while the single processor socket leaves room for a future second CPU upgrade up to 8 cores and 95 W.
Highlights
- Quad-core Xeon E-2434 at 3.4 GHz for responsive compute
- 16 GB DDR5 at 4800 MT/s for fast memory bandwidth
- 8 SFF hot-plug drive bays for flexible storage growth
- PCIe Gen5 x16 slot for high-speed expansion
- Dedicated iLO port simplifies remote management
Specifications
| Brand | HPE |
|---|---|
| Series | ProLiant |
| Model | ML30 Gen11 |
| Part Number | P65397-001 |
| Workload | Workstation |
| Type | Tower |
| Rack Height | 4U |
| CPU Type | Intel Xeon E-2434 / 3.4 GHz (, up to 5 GHz, (Quad-Core) |
| CPU Speed | 3.4 GHz |
| Number of CPU Cores | Quad-Core Processor |
| Cache Memory | 12 MB Intel Smart Cache |
| CPU Features | 1x Non-hot plug non-redundant system fan |
| # of Processors Installed | 1 |
| Installed Memory Size | 16GB |
| Memory Type | DDR5 |
| Shipping weight | 13.61 kg |
| Package size | 610 × 508 × 343 mm |
Questions about this item
Does the P65397-001 ship with drive trays for the 8SFF bays and a rail kit for 4U tower use?
The server includes the 8SFF hot-plug chassis and a 500W Flex Slot Platinum power supply; drive trays and rail kits are sold separately.
Should I select the 16 GB UDIMM or the 32 GB UDIMM to reach the 128 GB DDR5 limit?
Both 16 GB and 32 GB DDR5-4800 UDIMMs are validated; four 32 GB modules fill the 128 GB maximum with fewer slots used.
What does the Xeon E-2434 3.4 GHz base clock deliver once the CPU is installed in the ML30 Gen11?
The quad-core E-2434 runs at 3.4 GHz base with a 5 GHz turbo, 12 MB Smart Cache and a 95 W TDP inside the single-socket tower chassis.
