Green rectangular ATX motherboard with silver heatsinks, black slots and rear I/O ports visible

HUANANZHI

HUANANZHI X99 CH8 Intel motherboard LGA 2011

SKU CH-00E8-XRK1Y

An ATX workstation board for LGA 2011 Xeon CPUs with eight DDR4 slots, quad-channel memory, M.2 and U.2 NVME, six SATA 3.0 ports, 7.1 audio and gigabit Ethernet

  • CPU Socket TypeLGA 2011
  • Supports Intel Xeon E5 processors on LGA 2011-3 socket
  • Eight DDR4 slots deliver four-channel memory up to 2400 MHz
  • M.2 and U.2 NVMe interfaces at PCIe 3.0 x4 for fast storage
  • Six SATA 3.0 ports plus ten USB ports for broad connectivity
  • 1-channel audio and Gigabit Ethernet built in

X99 CH8 LGA 2011 workstation board

The HUANANZHI X99 CH8 is an ATX motherboard built around the Intel X99 chipset and LGA 2011 socket for Xeon E5 v3 and v4 processors. It targets system builders assembling render nodes, simulation workstations or multi-GPU compute rigs that need high core counts and quad-channel memory bandwidth. The ten-layer PCB and six-phase power delivery are designed for sustained loads in server-grade chassis.

Eight DDR4 slots and quad-channel support

Eight DDR4 DIMM slots run in four-channel mode at 2400, 2133 or 1866 MHz and accept both ECC and non-ECC modules up to the platform limit. Ten SATA 3.0 ports, one M.2 NVME slot and one U.2 connector provide dense storage connectivity for large datasets. The single PCIe 3.0 x16 slot and two x8 slots suit multi-GPU or accelerator configurations, while 7.1 audio and gigabit Ethernet cover baseline I/O. Builds needing newer CPU generations, integrated Wi-Fi or more than one full-length PCIe 3.0 x16 slot should choose a different platform.

LGA 2011 socket defines CPU choice

The LGA 2011 socket locks the board to Intel Xeon E5 v3 and v4 processors only; no other CPU generation fits. Buyers must confirm their processor matches this socket before purchase.

Highlights

  • Supports Intel Xeon E5 processors on LGA 2011-3 socket
  • Eight DDR4 slots deliver four-channel memory up to 2400 MHz
  • M.2 and U.2 NVMe interfaces at PCIe 3.0 x4 for fast storage
  • Six SATA 3.0 ports plus ten USB ports for broad connectivity
  • 1-channel audio and Gigabit Ethernet built in

Specifications

BrandHUANANZHI
SeriesX99
ModelX99 CH8
CPU Socket TypeLGA 2011

Questions about this item

How can I confirm the X99 CH8 is running correctly after I install it?

Power on the system and verify the BIOS detects all eight DDR4 slots, the four-channel memory at 2400/2133/1866 MHz, the M.2 NVME (X43.0) slot, the U.2 (X43.0) port, and the Gigabit Ethernet controller.

What comes in the box with the HUANANZHI X99 CH8 and what must I purchase separately?

The board ships with the 300 × 240 mm ATX motherboard only; you must supply an LGA 2011-3 Xeon processor, DDR4 memory modules, a 500 W or larger power supply with 24-pin and 8-pin connectors, storage drives, and a chassis.

Which version of the X99 CH8 should I choose for a workstation build?

Only the single X99 CH8 model is offered, featuring 10-layer PCB, six-phase power, one PCIe 3.0 x16, two PCIe 3.0 x8, one PCIe 2.0 x4, one M.2 NVME (X43.0), one U.2 (X43.0), six SATA 3.0 ports, 7.1 audio, and Gigabit Ethernet.
