Green rectangular motherboard with silver CPU socket, eight black DDR4 slots, multiple PCIe slots and rear I/O panel

HUANANZHI

HUANANZHI X99 CH8 LGA 2011-3 Intel motherboard

SKU CH-QSE9-0A2YP

LGA 2011-3 workstation board with eight DDR4 slots, four-channel memory, 7.1 audio, Gigabit Ethernet, M.2 and U.2 NVME, plus multiple PCIe 3.0 and 2.0 slots

  • CPU Socket TypeLGA 2011
  • Supports Intel Xeon E5 V3 and V4 processors via LGA 2011-3 socket
  • Eight DDR4 slots deliver four-channel memory bandwidth up to 2400 MHz
  • M.2 and U.2 interfaces both wired at PCIe 3.0 x4 for fast NVMe storage
  • Ten SATA 3.0 ports and multiple PCIe expansion slots for drives and add-in cards
  • 10-layer PCB with six-phase power delivery built on a 300 x 240 mm E-ATX board

HUANANZHI X99 CH8 LGA 2011-3 Motherboard

The HUANANZHI X99 CH8 is an Intel motherboard built for the LGA 2011-3 socket. It accepts Xeon E5 V3 and V4 processors such as the 2640, 2666, 2670, 2678 and 2696. Eight DDR4 slots provide four-channel memory support at 2400, 2133 and 1866 MHz for both ECC and non-ECC modules. The board measures 300 by 240 mm and uses a 10-layer PCB with a 6-phase power design.

Workstation and server builders needing multi-core

This board suits users building rendering nodes, virtualization hosts or storage servers that benefit from high core counts and quad-channel memory. It provides six SATA 3.0 ports, an M.2 NVMe slot (X4 3.0) and a U.2 port (X4 3.0) for fast storage arrays. Builds requiring modern consumer sockets, integrated wireless or newer platform features should consider current-generation alternatives.

Eight DDR4 slots with four-channel architecture

The defining specification is the eight DDR4 DIMM slots wired for four-channel operation at up to 2400 MHz. This density allows large memory capacities essential for virtualization, scientific computing and large dataset workloads. Confirm that your chosen Xeon processor and memory kit match the supported speeds and ECC preference before purchase.

Highlights

  • Supports Intel Xeon E5 V3 and V4 processors via LGA 2011-3 socket
  • Eight DDR4 slots deliver four-channel memory bandwidth up to 2400 MHz
  • M.2 and U.2 interfaces both wired at PCIe 3.0 x4 for fast NVMe storage
  • Ten SATA 3.0 ports and multiple PCIe expansion slots for drives and add-in cards
  • 10-layer PCB with six-phase power delivery built on a 300 x 240 mm E-ATX board

Specifications

BrandHUANANZHI
ModelX99 CH8
CPU Socket TypeLGA 2011

Questions about this item

Will the 6-phase power delivery sustain a Xeon E5-2696 v4 under continuous load?

The board uses a 10-layer PCB with 6-phase power delivery and requires at least a 500 W supply to support high-wattage Xeon processors.

How loud or hot does the board get when all eight DDR4 slots and both M.2 and U.2 drives are active all day?

Five fan headers let you tune airflow for the VRM and drives; the 10-layer design spreads heat, but acoustic and thermal results depend on your cooler and case airflow.

Which specific power cables must my PSU provide for this X99 CH8 motherboard?

You need a 24-pin ATX connector plus an 8-pin EPS connector to power the board.
