Green rectangular motherboard with silver heatsinks, eight black DDR4 slots, two large CPU sockets and multiple expansion slots

HUANANZHI

HUANANZHI X99 F8D PLUS Intel motherboard

SKU CH-7E1Z-Y7RA6

Dual-socket LGA 2011-3 board with eight DDR4 slots, six SATA 3.0 ports, dual Gigabit Ethernet and PCIe 3.0 M.2 NVMe support

  • CPU Socket TypeLGA 2011
  • Dual Intel Xeon support with LGA 2011-3 socket
  • Eight DDR4 slots up to 64 GB each in quad-channel 1866/2133/2400 MHz
  • Ten SATA 6 Gb/s ports plus M.2 NVMe PCIe 3.0 x4 and M.2 SATA
  • Three PCIe 3.0 x16 slots and dual gigabit Ethernet for expansion
  • 1-channel audio with front-panel USB 2.0, USB 3.0 and audio headers

Dual-CPU Workstation Platform

The HUANANZHI X99 F8D PLUS motherboard targets workstation builders who need dual Intel Xeon processor support on the LGA 2011-3 socket. Eight DDR4 slots enable four-channel memory at 1866 2133 or 2400 MHz with a maximum capacity of 64 GB per module. The C612 chipset family is shipped at random depending on stock availability.

Dense Storage and I/O Layout

Ten SATA 3.0 ports combine six standard connectors with four additional SSATA connections for high drive counts. Dual M.2 slots provide one 22110 NVMe PCIe 3.0 x4 interface at 32 Gb/s and one 2280 slot that shares an SSATA lane with SATA. Rear I/O supplies four USB 2.0 four USB 3.0 two Gigabit Ethernet ports and six 3.5 mm audio jacks for 7.1 surround sound. Internal headers add one 9-pin USB 2.0 one 19-pin USB 3.0 and front-panel audio.

Expansion Focused on Compute Density

Three full-length PCI Express 3.0 x16 slots allow multiple GPU or accelerator cards for rendering or compute workloads. The M.2 implementation requires attention because the 2280 slot consumes an SSATA signal when populated. No wireless or Bluetooth hardware is included on the board. A minimum 500 W power supply is advised by the manufacturer to sustain dual-CPU operation. The CMOS battery is removed before shipping due to postal regulations.

Highlights

  • Dual Intel Xeon support with LGA 2011-3 socket
  • Eight DDR4 slots up to 64 GB each in quad-channel 1866/2133/2400 MHz
  • Ten SATA 6 Gb/s ports plus M.2 NVMe PCIe 3.0 x4 and M.2 SATA
  • Three PCIe 3.0 x16 slots and dual gigabit Ethernet for expansion
  • 1-channel audio with front-panel USB 2.0, USB 3.0 and audio headers

Specifications

BrandHUANANZHI
ModelX99 F8D PLUS
CPU Socket TypeLGA 2011

Questions about this item

Will the board fit in a standard ATX case and what power supply do I need?

The board uses an ATX form factor and the supplier recommends at least a 500w power supply to support the dual-CPU platform.

Which memory modules are compatible and how much can I install?

Eight DDR4 slots support four-channel DDR4 at 1866, 2133 or 2400MHz with a maximum capacity of 8*64G.

What M.2 drives can I use and how are the slots wired?

One M.2 22110 slot runs NVME PCIE x4 3.0 at 32Gb/s; a second M.2 2280 slot runs PCIE x4 3.0 or SSATA 3.0 and shares one SSATA signal.
