Green E-ATX motherboard with dual LGA 2011 sockets, eight DDR3 slots, two large CPU coolers, four black memory sticks

HUANANZHI

HUANANZHI X99 T8D Intel motherboard with 2× Xeon E5-2673 V3 and 4×16 GB DDR3 RECC

SKU CH-GJTX-FAQEN

Dual 12-core Xeon E5-2673 V3 processors with 64 GB DDR3 RECC on an E-ATX board offering 8 DIMM slots, 10 SATA ports, dual M.2 NVMe and dual gigabit Ethernet

  • CPU Socket TypeLGA 2011
  • Dual Xeon E5-2673 V3 CPUs deliver 24 cores for heavy multitasking
  • 64 GB quad-channel DDR3 RECC memory supports error-corrected workloads
  • C612 chipset motherboard provides 6 SATA3 and 4 SSATA3 ports
  • Dual M.2 slots include one PCIe 3.0 x4 NVMe and one SATA interface
  • 12-phase power on 12-layer PCB with 24-pin plus dual 8-pin CPU power

Dual Xeon E5-2673 V3 workstation board

The HUANANZHI X99 T8D motherboard arrives with two Xeon E5-2673 V3 processors installed, each providing 12 cores and 24 threads at 2.40 GHz. The LGA 2011-3 socket platform targets multi-threaded workloads such as rendering, virtualization and scientific compute. Four 16 GB DDR3 RECC modules populate the quad-channel memory controller for a total of 64 GB with error correction.

Bundled memory and NVMe slot change capacity

The kit includes four matched 16 GB DDR3 RECC DIMMs running at up to 1866 MHz, removing the need to source registered ECC memory separately. An M.2 22110 slot wired for PCIe 3.0 x4 NVMe adds high-speed boot or scratch storage without occupying a PCIe expansion slot. A second M.2 2280 connector shares a SATA signal, so using it in NVMe mode disables one SATA port.

E-ATX layout needs a compatible chassis

The board measures 300 by 320 mm in E-ATX form factor and requires a case that accepts this size. Power delivery uses a 24-pin ATX connector plus two 8-pin EPS connectors, so the power supply must provide both. Twelve CPU fan headers are present; verify header placement against the cooler mounting pattern. The C612-class chipset may vary between revisions, which can affect PCIe lane allocation for the three x16 slots.

Highlights

  • Dual Xeon E5-2673 V3 CPUs deliver 24 cores for heavy multitasking
  • 64 GB quad-channel DDR3 RECC memory supports error-corrected workloads
  • C612 chipset motherboard provides 6 SATA3 and 4 SSATA3 ports
  • Dual M.2 slots include one PCIe 3.0 x4 NVMe and one SATA interface
  • 12-phase power on 12-layer PCB with 24-pin plus dual 8-pin CPU power

Specifications

CPU Socket TypeLGA 2011

Questions about this item

How often will the dual Xeon E5-2673 V3 processors need thermal paste replacement under continuous load?

The two CPUs each draw 105 W at 2.40 GHz with 12 cores and 24 threads, so plan to refresh thermal compound every two to three years if the system runs all day.

What limits the M.2 22110 NVME slot when the board is pushed hard for hours?

The slot runs at PCIe 3.0 x4, so sustained throughput caps at the bus ceiling of 32 Gb/s before the drive itself becomes the bottleneck.

How loud and hot does the 12-phase VRM area get with both 105 W CPUs and four 16 GB DDR3 RECC sticks running 24/7?

Six onboard fan headers let you move enough air over the 12-phase power delivery to keep VRM temperatures in check, while the dual Gigabit Ethernet and 7.1 audio add negligible extra heat.
