HYTE Y40 CS-HYTE-Y40-BW ATX Mid Tower PC case Black White
ATX mid-tower with panoramic tempered glass, PCIe 4.0 riser for vertical GPU mounting, and two pre-installed 120mm fans
- TypeATX Mid Tower
- ColorBlack / White
- Case MaterialABS / Steel / Tempered Glass
- Motherboard CompatibilityATX / Micro ATX / Mini ITX
- Side Panel2 x Sides Tempered Glass Panel
- Dust FiltersTop Side Bottom x 2
Options Y40 (White)
- Y40 (White)
- Y40 (Red)
- Y40 (Snow White)
Struck-through versions exist but are not stocked here.
- Panoramic dual tempered glass panels showcase every component
- PCIe 4.0 x16 riser cable included for vertical GPU mounting
- 422 mm GPU clearance supports the longest graphics cards
- 360 mm top radiator support enables high-capacity liquid cooling
- Two 120 mm 1300 rpm fans pre-installed for immediate airflow
Panoramic Glass ATX Mid Tower
The HYTE Y40 is a mid tower chassis built from steel, ABS and two full side panels of tempered glass. It accepts ATX, Micro ATX and Mini ITX motherboards and presents a bezel-less panoramic view of the internal hardware. A PCI Express 4.0 x16 riser cable is included so the graphics card can be mounted vertically in the four full-height expansion slots.
Riser Cable Routing And Fan Mounts
Installing the supplied riser cable requires routing it behind the motherboard tray and seating it firmly in the primary PCIe slot before the graphics card is attached vertically. The pre-installed 120 mm fans at the rear and beneath the floor use standard 4-pin connectors; the side bracket accepts two 120 mm or 140 mm fans, the top takes three 120 mm fans, and the bottom fits one 120 mm or 140 mm unit. Dust filters on the top, side and bottom panels lift out for cleaning without tools.
GPU Clearance And Radiator Limits
The vertical graphics orientation allows cards up to 422 mm long and 94 mm tall, though 80 mm or less is recommended for optimal airflow around the riser cable. CPU air coolers are limited to 183 mm in height. Radiator support reaches 360 mm at the top, 280 mm on the side with a 120 mm thickness limit, and 120 mm at the rear. The ATX power supply bay accommodates units up to 224 mm deep.
Highlights
- Panoramic dual tempered glass panels showcase every component
- PCIe 4.0 x16 riser cable included for vertical GPU mounting
- 422 mm GPU clearance supports the longest graphics cards
- 360 mm top radiator support enables high-capacity liquid cooling
- Two 120 mm 1300 rpm fans pre-installed for immediate airflow
Specifications
| Brand | HYTE |
|---|---|
| Series | Y40 |
| Model | CS-HYTE-Y40-BW |
| Type | ATX Mid Tower |
| Color | Black / White |
| Case Material | ABS / Steel / Tempered Glass |
| Motherboard Compatibility | ATX / Micro ATX / Mini ITX |
| Side Panel | 2 x Sides Tempered Glass Panel |
| Dust Filters | Top Side Bottom x 2 |
| Internal 3.5" Drive Bays | 1 x 3.5" HDD or 2 x 2.5" SSD |
| Expansion Slots | 4 + 6 half-height |
| Front Ports | 2 x USB 3.0, 1 x USB 3.2 Type-C/ 1 x Audio, |
| Fan Options | Side: 2x 120mm/140mm Top: 3x 120mm Rear: 1x 120mm (1x 120mm, 1300 rpm included) Bottom: 1x 120mm/140mm (1x 120mm, 1300 rpm included) |
| Pre-installed Fans | Bottom - 1 x 120mm / Rear - 1 x 120mm |
| Radiator Options | Side: 120, 140, 240, 280mm up to 120mm thick Top: 120, 240, 360mm Rear: 120mm |
| Max GPU Length | 422mm length, 94mm height (80mm height or less recommended for best cooling) |
| Max CPU Cooler Height | 183 mm |
| Max PSU Length | ATX up to 224mm in length |
| Dimensions | 21.15" x 12.88" x 20.67" |
| Weight | 22.91 lbs. |
| Shipping weight | 10.39 kg |
| Package size | 472 × 439 × 240 mm |
Other versions of this model
1 more in the same range
Same family, different memory, cooler or clock — compare before you commit.
Questions about this item
Will my 422 mm graphics card fit vertically with the included riser cable?
Yes, the case supports cards up to 422 mm length and 94 mm height when mounted vertically using the supplied PCIe 4.0 x16 riser cable.
What radiator sizes can I install on the side and top for liquid cooling?
The side bracket accepts 120, 140, 240 or 280 mm radiators up to 120 mm thick, while the top supports 120, 240 or 360 mm units.
How many 2.5 inch SSDs can I mount if I do not use a 3.5 inch hard drive?
The single 3.5 inch drive bay converts to two 2.5 inch SSD positions, giving you a maximum of two SSDs in that location.
