Black rectangular ATX PSU with 120mm fan and fixed cables

Inloom

Inloom BX500 500w ATX non-modular power supply

SKU CH-AHHN-NGWZ1 MPN BX500

ATX power supply delivering 500 W continuous power with 80 PLUS Bronze efficiency and a 120 mm fan

  • TypeATX
  • Maximum Power500w
  • ModularNon-Modular
  • Fans1 x 120 mm
  • Main Connector20+4 Pin
  • Efficiency> 80%
  • 80 PLUS Bronze certification keeps efficiency above 80 % under typical loads
  • Single 120 mm fan moves air through a compact 140 mm by 148 mm by 85 mm chassis
  • Two 6+2 pin PCIe connectors support SLI and CrossFire multi-GPU setups
  • Over-voltage and overload protection circuits guard components during power anomalies
  • Non-modular design with black braided cables simplifies cable routing in standard ATX cases

500 W ATX non-modular power supply

The Inloom BX500 is a 500 W ATX power supply with a fixed cable set and 80 PLUS Bronze certification. It follows Intel ATX 12V 2.31 and EPS 12V 2.92 specifications and includes over-voltage and overload protection. A single 120 mm fan provides cooling.

Entry builds and multi-GPU starters

Suits builders assembling a basic office or home PC who want Bronze-rated efficiency and SLI or CrossFire support. Not for systems that need modular cabling for tight cable routing or builds that require a higher continuous wattage than 500 W.

Two 6+2-pin PCIe connectors

The unit ships with two 6+2-pin PCIe connectors, allowing a single graphics card that needs up to two eight-pin inputs. If your card demands three or more PCIe power plugs, this supply cannot meet that requirement.

Highlights

  • 80 PLUS Bronze certification keeps efficiency above 80 % under typical loads
  • Single 120 mm fan moves air through a compact 140 mm by 148 mm by 85 mm chassis
  • Two 6+2 pin PCIe connectors support SLI and CrossFire multi-GPU setups
  • Over-voltage and overload protection circuits guard components during power anomalies
  • Non-modular design with black braided cables simplifies cable routing in standard ATX cases

Specifications

BrandAxora
ModelBX500
SeriesBX
TypeATX
Maximum Power500w
ModularNon-Modular
Fans1 x 120 mm
Main Connector20+4 Pin
Efficiency> 80%
Energy-Efficient80 PLUS BRONZE Certified
Over Voltage ProtectionYes
Overload ProtectionYes
SLIReady
CrossFireReady
Dimensions140mmx148mmx85mm
Weight3.3lbs
PCI-Express Connector2 x 6+2 Pin

Questions about this item

Which motherboard power connector does the BX500 use?

The unit provides a 20+4 pin main connector that fits standard ATX motherboards.

Can the two 6+2 pin PCIe connectors run an older graphics card that only needs a single 6 pin plug?

Yes, each 6+2 pin connector can be used as a straight 6 pin by leaving the extra two pins unattached.

How do I confirm the fan is spinning and the supply is delivering power after installation?

The 120 mm fan will rotate when the PSU is powered on and the system draws load, indicating normal operation.
