Intel
Intel BX8071513400 Core i5-13400 desktop processor
A 10-core desktop CPU with six performance and four efficient cores, up to 4.6 GHz boost, 20 MB L3 cache, integrated UHD 730 graphics, and DDR4-3200 or DDR5-4800 support on LGA 1700
- Processors TypeDesktop
- NameCore i5-13400
- CPU Socket TypeLGA 1700
- Core NameRaptor Lake
- # of Cores10-Core (6P+4E)
- # of Threads16-Threads
- 10 cores and 16 threads handle multi-tasking workloads
- Up to 4.6 GHz turbo frequency accelerates single-thread tasks
- 20 MB L3 cache reduces memory latency
- DDR4 3200 and DDR5 4800 support fits existing or new memory
- Intel UHD Graphics 730 provides display output without a discrete GPU
10-core LGA 1700 desktop processor
The Core i5-13400 combines six performance cores and four efficient cores for 16 threads on the LGA 1700 socket. It supports DDR4 3200 and DDR5 4800 memory across two channels up to 128 GB. Integrated Intel UHD Graphics 730 provides display output without a discrete card.
65 W base power with 148 W turbo ceiling
Under sustained workloads the processor runs at its 65 W base power with P-cores at 2.5 GHz and E-cores at 1.8 GHz. When thermal headroom allows it can lift to 148 W, pushing P-cores toward 4.6 GHz and E-cores toward 3.3 GHz. The 20 MB L3 cache and 9.5 MB L2 cache help maintain throughput during long sessions.
Cooler not included; install on LGA 1700
The boxed unit ships without a cooling device so a separate solution rated for at least 148 W is required. Mounting follows the standard LGA 1700 pattern; take care to seat the processor evenly and apply thermal paste before clamping. Memory and PCIe 5.0 or 4.0 devices install normally once the CPU is secured.
Highlights
- 10 cores and 16 threads handle multi-tasking workloads
- Up to 4.6 GHz turbo frequency accelerates single-thread tasks
- 20 MB L3 cache reduces memory latency
- DDR4 3200 and DDR5 4800 support fits existing or new memory
- Intel UHD Graphics 730 provides display output without a discrete GPU
Specifications
| Brand | Intel |
|---|---|
| Processors Type | Desktop |
| Series | Core i5 13th Gen |
| Name | Core i5-13400 |
| Model | BX8071513400 |
| CPU Socket Type | LGA 1700 |
| Core Name | Raptor Lake |
| # of Cores | 10-Core (6P+4E) |
| # of Threads | 16-Threads |
| Operating Frequency | P-core Base Frequency: 2.5 GHz E-core Base Frequency: 1.8 GHz |
| Max Turbo Frequency | P-core Max Turbo Frequency: Up to 4.6 GHz E-core Max Turbo Frequency: Up to 3.3 GHz |
| L2 Cache | 9.5MB |
| L3 Cache | 20MB |
| Memory Types | DDR4 3200 / DDR5 4800 |
| Memory Channel | 2 |
| Max Memory Size | 128 GB |
| Integrated Graphics | Intel UHD Graphics 730 |
| PCI Express Revision | 5.0 / 4.0 / 3.0 |
| Max Number of PCI Express Lanes | 20 |
| Thermal Design Power | Processor Base Power: 65W Maximum Turbo Power: 148W |
| Cooling Device | Cooling device not included - Processor Only |
| Operating System Supported | Windows 11 |
| Shipping weight | 0.48 kg |
| Package size | 124 × 109 × 84 mm |
Questions about this item
How loud and hot does the Core i5-13400 get when running at its 148W Maximum Turbo Power all day?
The processor has a 65W base power and can reach 148W at maximum turbo; actual noise and temperature depend entirely on the cooler you install, as no cooling device is included.
What memory and motherboard socket must I already own to use the Core i5-13400?
You need an LGA 1700 motherboard and either DDR4 3200 or DDR5 4800 memory running in dual-channel mode for up to 128GB capacity.
Will my existing PCIe 3.0 graphics card and DDR4 memory work with the Core i5-13400?
Yes, the CPU supports PCIe 5.0, 4.0 and 3.0 with 20 lanes total, and it works with both DDR4 3200 and DDR5 4800 memory types.
